FUNAI DDVR-6830 - Page 70

2050623 1-19-9 H9903EL
R552 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R557 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R558 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R560 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R562 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R567 CHIP RES.(1608) 1/10W J 39k Ω RRXAJR5Z0393
R568 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R569 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R570 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R572 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R574 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R575 CHIP RES.(1608) 1/10W J 330k Ω RRXAJR5Z0334
R576 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R577 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R578 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R581 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R582 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R583 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R584 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R585 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R586 CHIP RES.(1608) 1/10W J 820 Ω RRXAJR5Z0821
R588 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R590 B CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R591 A CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R601 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R602 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R603 CHIP RES.(1608) 1/10W J 1.2k Ω RRXAJR5Z0122
R604 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R605 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R609 CHIP RES.(1608) 1/10W J 5.1k Ω RRXAJR5Z0512
R610 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R613 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R614 CHIP RES.(1608) 1/10W J 5.1k Ω RRXAJR5Z0512
R615 CHIP RES.(1608) 1/10W J 5.1k Ω RRXAJR5Z0512
R616 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R617 PCB JUMPER D0.6-P5.0 JW5.0T
R618 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R624 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R703 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R704 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R705 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R706 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R707 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R756 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R757 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R759 CARBON RES. 1/6W J 150 Ω or RCX6JATZ0151
CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R760 CHIP RES.(1608) 1/10W J 150 Ω RRXAJR5Z0151
R761 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R762 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R763 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R764 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R767 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R768 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R769 PCB JUMPER D0.6-P5.0 JW5.0T
R902 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R931 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R932 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R933 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R941 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R942 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R943 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1056 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1057 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1061 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1062 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
Ref. No. Mark Description Part No.
R1065 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1066 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R1067 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1068 CARBON RES. 1/6W J 390 Ω or RCX6JATZ0391
CARBON RES. 1/4W J 390 Ω RCX4JATZ0391
R1071 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1072 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1085 CHIP RES.(1608) 1/10W F 75 Ω or RRXAFR5H0750
CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5Z0750
R1086 CHIP RES.(1608) 1/10W F 2.0k Ω or RRXAFR5H0202
CHIP RES. 1/10W F 2.0k Ω RRXAFR5Z0202
R1087 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1090 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1091 CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJR5Z0332
R1205 CHIP RES.(1608) 1/10W F 20k Ω or RRXAFR5H2002
CHIP RES.(1608) 1/10W F 20k Ω RRXAFR5Z2002
R1206 CHIP RES.(1608) 1/10W F 20k Ω or RRXAFR5H2002
CHIP RES.(1608) 1/10W F 20k Ω RRXAFR5Z2002
R1207 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R1208 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R1209 CHIP RES.(1608) 1/10W F 30k Ω or RRXAFR5H3002
CHIP RES.(1608) 1/10W F 30k Ω RRXAFR5Z3002
R1210 CHIP RES.(1608) 1/10W F 30k Ω or RRXAFR5H3002
CHIP RES.(1608) 1/10W F 30k Ω RRXAFR5Z3002
R1211 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1221 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1222 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1223 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1224 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1227 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1228 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1229 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1238 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1240 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1245 CHIP RES.(1608) 1/10W J 10 Ω RRXAJR5Z0100
R1352 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1353 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1354 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1355 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1356 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1361 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1394 CARBON RES. 1/6W J 100 Ω or RCX6JATZ0101
CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1396 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1421 CHIP RES. 1/10W F 160 Ω or RRXAFR5H1600
CHIP RES. 1/10W F 160 Ω RRXAFR5Z1600
R1422 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1423 CHIP RES. 1/10W F 160 Ω or RRXAFR5H1600
CHIP RES. 1/10W F 160 Ω RRXAFR5Z1600
R1442 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1501 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1502 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1503 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R2001 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2002 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2003 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2005 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2006 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2067 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2086 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R2093 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R2094 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
SWITCHES
SW501 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW502 TACT SWITCH KSM0614B or SST0101HH013
