FUNAI DDVR-6830 - Page 71

2050623 1-19-10 H9903EL
DVD OPEN/CLOSE CBA
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW503 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW504 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW506 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW507 ROTARY MODE SWITCH SSS-53MD SSR0106KB003
SW601 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW602 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW603 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW604 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW605 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2021 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW2022 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
A5 JACK BOARD(RCA) H9700ED 0VM204532
2B11 NEW SHIELD ASSEMBLY H9700ED 1VM420438
2B15 BUSH LED(F) H3700UD 0VM409508
2B46 ROHM HOLDER H7770JD 0VM304573
JK101 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JK751 RCA JACK 2P MSP-282V-12 NI LF(B1 JXRL020LY121
JK752 RCA JACK(YELLOW) MSP-281V4-B JXRL010LY003
JK753 RCA JACK(WHITE) MSP-281V1-B JXRL010LY005
JK754 RCA JACK(RED) MSP-281V3-A JYRL010LY002
JK1202 RCA JACK(BLACK) MSP-281V2-B JXRL010LY062
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
JW006 FFC CABLE 27P FFC/P1.00/260 WX1H9700-001
JW007 FFC CABLE 18P FFC/P1.00/170 WX1H9900-001
2L062 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080
2L082 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
RM2001 REMOTE RECEIVER MIM-93M6DKF or USESJRSUNT01
REMOTE RECEIVER PIC-37042LU USESJRSKK033
TP301 PCB JUMPER D0.6-P19.0 JW19.0T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP503 PCB JUMPER D0.6-P6.0 JW6.0T
TP504 PCB JUMPER D0.6-P15.0 JW15.0T
TU701 TUNER UNIT TMDG9-861A UTUNPLGAL015
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN004
XTAL 1K*044334EE or FXC445LDS002
QUARTZ CRYSTAL 4.433619MHz or FXC445LCHE01
XTAL 4.433619MHz or FXC445LLN001
XTAL 4.433619MHz 1811388
X501 XTAL 12.000MHz or FXD126LDS001
QUARTS CRYSTAL 12.000000MHz FXD126LCHE01
X502 XTAL 32.768kHz (20PPM) or FXC323LQUA01
XTAL 32.768kHz (20PPM) FXC323LDS002
Ref. No. Mark Description Part No.
Ref. No. Mark Description Part No.
DVD OPEN/CLOSE CBA (MCV-C)
Consists of the following:
---------
SWITCHES
SW2020 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW008 JUMPER WIRE 2P AWG26#2651/P2.0/
130
WX1H7375-001
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
1VSA10047
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
PSV CBA
Consists of the following:
1VSA11150
POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
JACK-A CBA (PSV-C)
---------
---------
---------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
---------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CE1JMASTL100
C014 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C015 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C017 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASDL102
ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPTL102
C018 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C020 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M CE1JMASTL220
C021 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C022 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTL471
C1001! METALIZED FILM CAP. 0.068µF/250V K
or
CT2E683DC011
! METALIZED FILM CAP. 0.068µF/250V K
or
CT2E683DC014
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C1004 ELECTROLYTIC CAP. 100µF/400V M CA2H101S6016
C1005 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C1006! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C1007 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASTL102
C1013 CERAMIC CAP.(AX) X K 3300pF/16V CCA1CKT0X332
