FUNAI DDVR-6830 - Page 72

2050623 1-19-11 H9903EL
C1018 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTL101
C1021 CERAMIC CAP.(AX) F Z 0.01µF/25V CDA1EZT0F103
C1025 CHIP CERAMIC CAP. B K 0.068µF/50V
or
CHD1JK30B683
CHIP CERAMIC CAP. B K 0.068µF/25V CHD1EK30B683
C1029 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C1032 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1033 CERAMIC CAP. YV Z 0.022µF/50V CCD1JZSYV223
C1035 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1106 ELECTROLYTIC CAP. 100µF/35V M or CE1GMASDL101
ELECTROLYTIC CAP. 100µF/35V M CE1GMASTL101
C1107 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASTL221
C2014 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C2015 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
DIODES
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D014 SCHOTTKY BARRIER DIODE SB390 NDQZ000SB390
D016 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D017 ZENER DIODE DZ-18BSAT265 or NDTA00DZ18BS
ZENER DIODE MTZJT-7718A QDTA00MTZJ18
D018 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D019 RECTIFIER DIODE FR203-B/P NDQZ000FR203
D1001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1003 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1004 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1011 RECTIFIER DIODE BA159 or NDQZ000BA159
RECTIFIER DIODE BA159 NDWZ000BA159
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 RECTIFIER DIODE FR101 NDWZ000FR101
D1017 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1019 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1030 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
ICS
IC1001! PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
COILS
L010 CHOKE COIL 47µH or LLBD00PKV022
Ref. No. Mark Description Part No.
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L013 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1001 BEAD CORE ASSEMBLY H9900ED 1VSA11421
L1002 BEAD CORE ASSEMBLY H9900ED 1VSA11421
L1003! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503 LLBG00ZKQ009
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1005 BEAD CORE ASSEMBLY H9900ED 1VSA11421
L1009 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1011 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1012 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
TRANSISTORS
Q1001! FET 2SK3566 QFWZ02SK3566
Q1003 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q1004 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR 2SA1175(J) or QQSJ02SA1175
TRANSISTOR 2SA1175(H) or QQSH02SA1175
TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(Y) or NQSY0KTA1267
TRANSISTOR KTA1267(GR) NQS10KTA1267
Q1008 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
RESISTORS
R057 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
Ref. No. Mark Description Part No.
