2050623 1-19-12 H9903EL
JUNCTION CBA
JACK-A CBA
AFV CBA
METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZQZ0823
METAL OXIDE FILM RES. 2W J 82k Ω RN02JZPZ0823
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1007 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1008 CARBON RES. 1/4W G 680 Ω RCX4GATZ0681
R1010 CARBON RES. 1/6W J 8.2k Ω or RCX6JATZ0822
CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R1011 METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZLZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZQZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1021 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1022 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES.(1608) 1/10W F 2.2k Ω RRXAFR5Z0222
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/4W G 1k Ω RCX4GATZ0102
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 15 Ω RCX4JATZ0150
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7KE009
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1059 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R1126 CHIP RES.(1608) 1/10W J 33k Ω RRXAJR5Z0333
MISCELLANEOUS
AC1001! AC CORD PE8G2CG9G0AA059 WAE0172LW009
2B33 HEATSINK H9700ED 0VM416271
F1001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
2L053 SCREW S-TIGHT M3X8 BIND HEAD+ GBMS3080
T0011! PULSE TRANS BCK-28-0552 or LTT00EPXB019
! PULSE TRANS CGS-SW0087A LTT00EPSA177
Ref. No. Mark Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
---------
CONNECTOR
CN051A 242 SERIES CONNECTOR TUC-P17X-
B1 WHT ST
JCTUB17TG002
MISCELLANEOUS
JW001 FLAT CABLE 8P AWG26#2651/P2.0/75 WX3808S6FF07
JW002 FLAT CABLE 9P AWG26#2651/P2.0/65 WX3809S6FF06
Ref. No. Mark Description Part No.
Ref. No. Mark Description Part No.
JACK-A CBA (PSV-C)
Consists of the following:
---------
CAPACITORS
C101 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C102 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C103 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C105 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C106 CHIP CERAMIC CAP.(1608) CH J
470pF/50V or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C108 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C110 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C111 CHIP CERAMIC CAP.(1608) CH J
470pF/50V or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C119 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
DIODES
D112 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D113 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COIL
L102 BEAD CORE ASSEMBLY H9900ED 1VSA11421
TRANSISTORS
Q103 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
RESISTORS
R111 CARBON RES. 1/6W J 220 Ω or RCX6JATZ0221
CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R114 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R117 CARBON RES. 1/4W J 510 Ω RCX4JATZ0511
R118 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R120 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R123 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R125 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R126 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
MISCELLANEOUS
JK1402 RGB CONNECTOR MRC-021V-03 JXGL210LY003
JW003 FLAT CABLE 10P AWG26#2651/P2.0/
190
WX3810S6FF19
Ref. No. Mark Description Part No.
AFV CBA
Consists of the following:
1VSA11123
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C4 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C6 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
