FUNAI DDVR-6830 - Page 74

2050623 1-19-13 H9903EL
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 CE1JMASSL3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
C26 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-
1-09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC1 IC AUDIO PROCESSOR MSP3417G-
QG-B8-V3
NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R4 CHIP RES.(1608) 1/10W J 120k Ω RRXAJR5Z0124
R5 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Mark Description Part No.
