FUNAI DPVR-2605 - IC Pin Function Descriptions

1-13-1 H9300PIN
IC PIN FUNCTION DESCRIPTIONS
[ VCR Section ]
IC501( SERVO / SYSTEM CONTROL IC )
“H” ≥ 4.5V, “L” ≤ 1.0V
Pin
No.
IN/
OUT
Signal
Name
Function
Active
Level
1IN
SC2-IN
Input Signal from
Pin 8 of SCART2
L/Hi-z
2IN
PG-
DELAY
Video Head
Switching Pulse
Signal Adjusted
Voltage
A/D
3IN
POW-
SAF
P-ON Power
Detection Input
Signal
A/D
4IN
END-S
Tape End Position
Detect Signal
A/D
5IN
AFC
Automatic Frequency
Control Signal
A/D
6IN
V-ENV
Video Envelope
Comparator Signal
A/D
7IN
KEY-1
Key Scan Input
Signal 1
A/D
8IN
KEY-2
Key Scan Input
Signal 2
A/D
9IN
LD-SW
Deck Mode Position
Detector Signal
A/D
10 OUT
ST-S
Tape Start Position
Detector Signal
A/D
11 -
N.U. Not Used
-
12 -
N.U. Not Used
-
13 OUT
D-V-
SYNC
Dummy V-sync
Output
H/Hi-z
14 IN
REMOCO
N
Remote
Control Sensor
L
15 OUT
C-ROTA
Color Phase Rotary
Changeover SIgnal
H/L
16 OUT
H-A-SW
Video Head Amp
Switching Pulse
H/L
17 IN
H-A-
COMP
Head Amp
Comparator Signal
H/L
18 OUT
RF-SW
Video Head
Switching Pulse
H/L
19 OUT
Hi-Fi-H-
SW
HiFi Audio Head
Switching Pulse
H/L
20 IN
DAVN-L
VPS/PDC Data
Receive = “L”
L
21 -
N.U. Not Used
-
22 -
N.U. Not Used
-
23 OUT
POWER
LED
“POWER” LED
Signal Output
H/L
24 OUT CAS LED
“CASSETTE” LED
Signal Output
H/L
25 OUT
TIMER
LED
“TIMER” LED Signal
Output
H/L
26 OUT REC LED
“REC” LED Signal
Output
H/L
27 -
N.U. Not Used
-
28 OUT
RGB-
THROUGH
SCART 2 RGB
Through Control
Signal
L/Hi-z
29 OUT DVD LED
“DVD” LED Signal
Output
H/L
30 OUT VCR LED
“VCR” LED Signal
Output
H/L
31 IN
REC-SAF-
SW
Recoding Safety SW
Detect (With Record
tab=”L”/ With out
Record tab=”H”)
H/L
32 -
N.U. Not Used
-
33 -
N.U. Not Used
-
34 IN
RESET
System Reset
Signal (Reset=”L”)
L
35 IN
XC
IN
Sub Clock
-
36 OUT
XC
OUT
Sub Clock
-
37 -
Vcc Vcc
-
38 IN
X
IN
Main Clock Input
-
39 OUT
X
OUT
Main Clock Input
-
40 -
Vss Vss(GND)
-
41 -
N.U. Not Used
-
42 -
DVD-
8PIN-IN
SCART 8Pin DVD
Input Control Signal
H/L
43 IN
CLKSEL Clock Select (GND)
L
44 IN
OSC
IN
Clock Input
for letter size
-
45 OUT
OSC
OUT
Clock Output for letter
size
-
46 -
NUB Not Used
-
47 -
PG/LP PG/LP
-
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock Input
-
49 -
OSDVss OSDVss
-
50 IN
OSD-V-IN
OSD Video Signal
Input
-
51 -
N.U. Not Used
-
