FUNAI DPVR-2605 - Mechanical Parts List

20020717 3-2-1 H9300CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
!
have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
DPVR-2600 A
DPVR-2700 B
DPVR-2605 C
Ref. No. Mark Description Part No.
A1X A,B FRONT ASSEMBLY H9300ED 0VM203743
A1X C FRONT ASSEMBLY H9320ED 0VM203747
A2 TOP COVER H9200UD 0VM101107
A3 CHASSIS H9200UD 0VM101106B
A4 PANEL, REAR H9300ED 0VM203725
A10! A LABEL, RATING H9300ED ----------
A10! B LABEL, RATING H9306ED ----------
A10! C LABEL, RATING H9320ED ----------
A11 LABEL, RESET H9300ED 0VM414073
A14 LABEL, SERIAL NO. H39H0JD(JPN) 0VM409906
A14 A,C LABEL, BAR CODE H9300ED 0VM414079
A14 B LABEL, BAR CODE H9306ED 0VM414084
A20 A,B TRAY ASSEMBLY H9300ED 0VM414050
A20 C PANEL, TRAY H9320ED 0VM414061
A31 LABEL, LASER CAUTION E5612BD 0VM413744
1B1 DECK ASSEMBLY CZD011/VM15E0 N15E0FL
1B2 DVD MECHA N79F1FVM
2B1 DECK PEDESTAL-1 H9200UD 0VM101108-1
2B2 TOP BRACKET H9100UD 0VM203252
2B3 SIDE BRACKET H9100UD 0VM305013
2B6 DECK PEDESTAL-2 H9200UD 0VM101108-2
2B9 CUSHION HC460ED 0VM413251
2B10 SIDE CUSHION HC470ED 0VM413392
2B16 TAPE, HIMELON H9206JD 0VM413956
2B18 TOP PLATE H9100UD 0VM412565
2B20 EARTH PLATE H9100UD 0VM305011
2B37 WIRE TAPE K3220UA 0VM404993
2B39 WASHER(D8) H1600UD 0VM408931
2B40 INSULATOR H9311BD 0VM203691
2B41 BRACKET H9311BD 0VM413935
2B48 TOP PLATE(2) H9100UD 0VM412699
2L021 SCREW, S-TIGHT H9210UD 0VM413231
2L022 S-TIGHT SCREW 3X8 BIND + CHROME GBMS3080
2L031 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L032 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L034 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L035 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
2L036 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
2L037 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L041 SCREW, C-TIGHT M3X5 BIND HEAD + GBCC3050
2L051 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L054 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L062 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L071 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
PACKING
S1 A,B GIFT BOX CARTON H9300ED 0VM305707
S1 C GIFT BOX CARTON H9320ED 0VM305711
S2 STYROFOAM(2) H9100UD 0VM203377A
S3 SET BAG E7708UA 0DM400731C
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/CRC006 NA204ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M WPZ0122LG001
X4 ACCESSORY BAG K8092BA 0VM404632
X5 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X6! B OWNER'S MANUAL(SPANISH) H9306ED 0VMN03250
X20! A,C OWNER'S MANUAL H9300ED 0VMN03224
X20! B OWNER'S MANUAL H9306ED 0VMN03233
Ref. No. Mark Description Part No.
