FUNAI DPVR-2605 - Electrical Parts List

20020717 3-3-1 H9300EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
!
have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
Parts that are not assigned part numbers (---------) are
not available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
Comparison Chart of Models and Marks
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DPVR-2600 A
DPVR-2700 B
DPVR-2605 C
Ref. No. Mark Description Part No.
DVD MAIN CBA UNIT N7TG6FEP
Ref. No. Mark Description Part No.
A
B
C
MCV CBA
MCV CBA
MCV CBA
Consists of the following
0VSA13125
0VSA13132
0VSA13137
MAIN CBA(MCV-A)
FUNCTION CBA(MCV-B)
FRONT JACK CBA(MCV-C)
JUNCTION A CBA(MCV-E)
JUNCTION B CBA (MCV-F)
SENSOR CBA
----------
----------
----------
----------
----------
0VSA13013
Ref. No. Mark Description Part No.
Main CBA(MCV-A) ----------
Consists of the following:
CAPACITORS
C055 ELECTROLYTIC CAP. 100µF/25V M or CE1EMASDL101
ELECTROLYTIC CAP. 100µF/25V M CE1EMASTL101
C056 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C057 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C058 ELECTRIC DOUBLE LAYER CAP0.047F/
5.5V Z or
CA0J473NE003
ELECTRIC DOUBLE LAYER CAP. 0.047F/
5.5V Z
CA0J473MS014
C059 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C060 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C063 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C101 ELECTROLYTIC CAP. 4.7µF/50V M or CE1JMASDL4R7
ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASTL4R7
C102 ELECTROLYTIC CAP. 4.7µF/50V M or CE1JMASDL4R7
ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASTL4R7
C103 ELECTROLYTIC CAP. 4.7µF/50V M or CE1JMASDL4R7
ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASTL4R7
C104 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C105 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C106 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C107 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C108 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C109 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C110 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C111 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C112 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C113 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C114 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C117 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C118 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C119 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C121 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C127 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C253 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C301 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
C302 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C303 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C306 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C307 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
