FUNAI DPVR-2605 - Page 57

1-13-3 H9300PIN
IC2001 [ PT6315-S(TP) ]
Pin
No.
In/Out
Signal
Name
Name Function
1 In CLK
Clock Input
2 In STB
Serial Interface Strobe
3 In K1
Key Data 1 Input
4 In K2
Key Data 2 Input
5 - VSS
GND
6 - VDD
Power Supply
7 Out a / KEY-1
Segment Output / Key
Souce-1
8 Out b / KEY-2
Segment Output / Key
Souce-2
9 Out c
Segment Output
10 Out d / KEY-4
Segment Output/ Key
Souce-4
11 Out e
Segment Output
12 In f
13 In g
14 Out h
15 - VEE
Pull Down Level
16 Out i
Segment Output
17
Out
7G
Grid Output
18 6G
19 5G
20 4G
21 3G
22 2G
23 1G
24 - VDD
Power Supply
25 - VSS
GND
26 In OSC
Oscillator Input
27 Out DOUT
Serial Data Output
28 In DIN
Serial Data Input
