2-4-2 DUALPALDA
(1): Follow steps in sequence. When reassembling, follow the steps in reverse order.
These numbers are also used as identification (location) No. of parts in the figures.
(2): Indicates the part to start disassembling with in order to disassemble the part in column (1).
(3): Name of the part
(4): Location of the part: T=Top B=Bottom R=Right L=Left
(5): Figure Number
(6): Identification of parts to be removed, unhooked, unlocked, released, unplugged, unclamped, or desoldered.
P=Spring, W=Washer, C=Cut Washer, S=Screw, *=Unhook, Unlock, Release, Unplug, or Desolder
e.g., 2(L-2) = two Locking Tabs (L-2).
(7): Adjustment Information for Installation
(+):Refer to Deck Exploded Views for lubrication.
.
[35] [25]
Loading Arm S(B)
Assembly
B DM2,DM15
(+)Refer to Alignment
Sec.Pg.2-4-9
[36] [35]
Loading Arm T(B)
Assembly
B DM2,DM15
(+)Refer to Alignment
Sec.Pg.2-4-9
[37] [2],[25]
M Brake T(HI) Assembly T DM1,DM16 *(P-6)
[38] [2],[25] M Brake S(HI) Assembly T DM1,DM16 *(P-7)
[39] [38]
Tension Lever Sub
Assembly
T DM1,DM16
[40] [39]
T Lever Holder T DM1,DM16 *(L-6)
[41] [2]
M Gear(HYT) T DM1,DM16 (C-7)
[42] [2],[15] Sensor Gear T DM1,DM16 (C-8)
[43] [37],[41] Reel T T DM1,DM16
[44] [39]
Reel S T DM1,DM16
[45] [35],[38]
Moving Guide S
Preparation
T DM1,DM17
[46] [36]
Moving Guide T
Preparation
T DM1,DM17
[47] [19] TG Post Assembly T DM1,DM17 *(L-7)
[48] [18],[28]
Rack Assembly R DM18
(+)Refer to Alignment
Sec.Pg.2-4-10
[49] [48]
F Door Opener R DM18
[50] [50] Cleaner Lever Assembly T DM1,DM6
Type A
*(L-8) Type B
[51] [50] CL Post T DM6 *(L-9) Type A
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
↓
(6)
↓
(7)
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
To Next Page
