FUNAI DPVR-2605 - Page 88

20020717 3-3-5 H9300EL
D118 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D119 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D121 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D301 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D510 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 ZENER DIODE DZ-7.5BSAT265 or NDTA0DZ7R5BS
ZENER DIODE MTZJT-777.5A QDTA0MTZJ7R5
D512 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D513 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D555 LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D701 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS
ZENER DIODE MTZJT-7733D QDTD00MTZJ33
D751 ZENER DIODE DZ-8.2BSAT265 or NDTA0DZ8R2BS
ZENER DIODE MTZJT-778.2A QDTA0MTZJ8R2
D1051 PCB JUMPER D0.6-P10.0 JW10.0T
D1052 ZENER DIODE DZ-13BSBT265 or NDTB00DZ13BS
ZENER DIODE MTZJT-7713B QDTB00MTZJ13
D1053 PCB JUMPER D0.6-P10.0 JW10.0T
D1056 PCB JUMPER D0.6-P10.0 JW10.0T
D1060 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1401 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1402 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1501 PCB JUMPER D0.6-P5.0 JW5.0T
LED EXCLUSIVE(A)
D506 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D507 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D508 LED(RED) 204HD/E NPQZ00204HDE
LED EXCLUSIVE(B)
D506 LED(GREEN) LTL-4231N NPQZLTL4231N
D507 LED(GREEN) LTL-4231N NPQZLTL4231N
D508 LED(RED) LTL-4211N NPQZLTL4211N
ICS
IC301 IC:Y/C/A LA71750AM-MTB QSZBA0RSY020
IC451 IC:HIFI LA72646M-A-MPB QSZBA0RSY022
IC501 MICROCONTROLLER 16BIT
M37762MCA-1C2GP or
QSZAA0RMB131
MICROCONTROLLER 16BIT
M37762MCA-1D5GP
QSZAB0RMB131
IC502 IC:MEMORY BR24C02F-W or QSMBA0SRM003
IC:MEMORY AT24C02N-10SC or NSMMA0SAZ012
IC:EEPROM M24C02-MN6T or NSMMA0TSS023
IC:EEPROM CAT24WC02JI NSZBA0SBG001
IC751 IC:SWITCH TC4053BF(N) or QSMBA0STS002
IC:SWITCH BU4053BCF-E2 QSMDA0TRM010
IC1052! 1.8V REGULATOR PQ018EF01SZ QSZBA0SSH012
IC1053 IC KIA431-AT NSZLA0TJY001
IC1201 IC:OP AMP KIA4558P or NSZBA0SJY004
IC:OP AMP NJM4558D QSZBA0SJR006
IC1204 FIBER OPTIC TRANS.MODULE 0C-
0805T-002 or
JWHHA00JD002
Ref. No. Mark Description Part No.
FIBER OPTIC TRANS.MODULE
GP1FA512TZV
JWHHA00SH003
IC1402 DRIVER FOR DVD(6CH) MM1567AJ QSZBA0SMM084
COILS
L051 PCB JUMPER D0.6-P5.0 JW5.0T
L052 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L053 INDUCTOR 100µH-K-26T LLAXKATTU101
L101 BEAD CORE B16 RH 3.5X10X1.3 or XL03010XM001
BEAD CORE HF70BB3.5X10X1.3 XL03010TE001
L102 BEAD CORE B16 RH 3.5X10X1.3 or XL03010XM001
BEAD CORE HF70BB3.5X10X1.3 XL03010TE001
L251 INDUCTOR 5.6µH-K-26T LLAXKATTU5R6
L302 INDUCTOR 56µH-K-26T LLAXKATTU560
L401 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L402 INDUCTOR 47µH-K-5FT LLARKBSTU470
L451 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L452 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L501 INDUCTOR 100µH-K-26T LLAXKATTU101
L502 PCB JUMPER D0.6-P5.0 JW5.0T
L503 INDUCTOR 1.8µH-K-26T LLAXKATTU1R8
L701 INDUCTOR 15µH-K-26T LLAXKATTU150
L702 PCB JUMPER D0.6-P5.0 JW5.0T
L703 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L704 INDUCTOR 10µH-K-26T LLAXKATTU100
L1251 INDUCTOR 0.47µH-K-26T LLAXKATTUR47
L1521 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
TRANSISTORS
Q051 TRANSISTOR KTA1281(Y) or NQSY0KTA1281
TRANSISTOR 2SA1020(Y) or QQSY02SA1020
TRANSISTOR 2SB892(S) QQSS002SB892
Q052 RES. BUILT-IN TRANSISTOR KRC103M or NQSZ0KRC103M
RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
Q053 RES. BUILT-IN TRANSISTOR KRA104M or NQSZ0KRA104M
RES. BUILT-IN TRANSISTOR BN1L4M-T QQSZ00BN1L4M
Q054 RES. BUILT-IN TRANSISTOR KRC103M or NQSZ0KRC103M
RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
Q055 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q056 TRANSISTOR KTC3203(Y) or NQSY0KTC3203
TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120
Q057 RES. BUILT-IN TRANSISTOR KRA103M or NQSZ0KRA103M
RES. BUILT-IN TRANSISTOR BN1F4M-T QQSZ00BN1F4M
Q101 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q102 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
Ref. No. Mark Description Part No.
