20020717 3-3-10 H9300EL
FUNCTION CBA
FRONT JACK CBA
SW508 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW511 TACT SWITCH KSM0611B SST0101HH004
SW2011 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2012 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2016 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2017 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
MISCELLANEOUS
2B11 SHIELD ASSEMBLY H9311BD 0VM413854
2B15 BUSH, LED(F) H3700UD 0VM409508
JK101 21P RGB JACK AJ-2050-040 JXGL210JD002
JK102 21P RGB JACK AJ-2050-040 JXGL210JD002
JK751 RCA JACK MSP-382V-12 PBSN JXRL020LY063
JK1202 RCA JACK(BLACK) MSP-281V2-B JXRL010LY062
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
JW002 FFC CABLE, 10P FFC/P1.25/160 WX1H9200-006
JW003 FFC CABLE, 26P FFC/P1.00/190 WX1H9200-003
JW004 FFC CABLE, 21P FFC/P1.00/300 WX1H9311-002
JW005 FFC CABLE, 10P FFC/P1.00/180 WX1H9200-011
JW006 PARALLEL WIRE, 10P AWG26#2651/P2.0/
65
WX1H9200-009
JW007 PARALLEL WIRE, 7P AWG26#2651/P2.0/
110
WX3807S6FF11
JW008 PARALLEL WIRE, 7P AWG26#2651/P2.0/
110
WX3807S6FF11
JW009 PARALLEL WIRE, 6P AWG26#2651/P2.0/
180
WX3806S6FF18
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
TP301 PCB JUMPER D0.6-P6.0 JW6.0T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP503 PCB JUMPER D0.6-P6.0 JW6.0T
TP504 PCB JUMPER D0.6-P5.0 JW5.0T
TP751 PCB JUMPER D0.6-P28.0 JW28.0T
TU701 TUNER UNIT TMDG2-631A UTUNPLBAL012
VR501 CARBON P.O.T. 100k Ω B VRCB104HH014
X301 X'TAL 4.433619MHz or FXC445LLN001
X'TAL 4.433619MHz 1811388
X501 X'TAL 12.000MHz FXD126LDS001
X502 X'TAL 32.768kHz(20PPM) or FXC323LQUA01
X'TAL 32.768kHz(20PPM) or FXC323LDS002
X'TAL 32.768kHz(20PPM) FXC323LCT001
Ref. No. Description Part No.
FUNCTION CBA (MCV-B) ----------
Consists of the following:
CAPACITORS
C2001 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C2002 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C2010 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JK30B472
C2012 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
Ref. No. Mark Description Part No.
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C2055 ELECTROLYTIC CAP. 22µF/50V M H7 CE1JMAVSL220
CONNECTOR
CN2001 FMN CONNECTOR, SIDE 10P 10FMN-STK JCFNG10JG003
DIODES
D2001 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2003 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2004 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2005 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC2001 FL DRIVER IC PT6315-S(-TP) NSZBA0TG2002
COILS
L2001 INDUCTOR 100µH-K-26T LLAXKATTU101
L2003 PCB JUMPER D0.6-P5.0 JW5.0T
L2004 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q2022 TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
RESISTORS
R1041 PCB JUMPER D0.6-P5.0 JW5.0T
R2001 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R2002 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2003 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2005 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R2006 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R2010 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R2011 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2031 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R2032 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R2034 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R2037 PCB JUMPER D0.6-P5.0 JW5.0T
R2038 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R2059 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
SWITCH
SW2014 TACT SWITCH KSM0614B or SST0101HH013
MISCELLANEOUS
FL2001 V.F.D. 20U29100SAN TVFD150FT007
RM2001 REMOTE RECEIVER MIM-93M6DKF USESJRSUNT01
TACT SWITCH SKQSAF001A SST0101AL041
Ref. No. Description Part No.
FRONT JACK CBA (MCV-C) ----------
Consists of the following:
CAPACITORS
C651 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C652 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
LED EXCLUSIVE(A)
DIODES
LED EXCLUSIVE(A)
D651 LED(RED) 204HD/E NPQZ00204HDE
D652 LED(RED) 204HD/E NPQZ00204HDE
Ref. No. Description Part No.
