1-15-2 E8B05PIN
43 IN
CLKSEL
Clock Select
(GND)
L
44 IN
OSCin
Clock Input for
letter size
-
45 OUT
OSCout
Clock Output
for letter size
-
46 -
NUB Not Used
-
47 IN
LP LP
-
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock
Input
-
49 -
OSDVss OSDVss
-
50 IN
OSD-V-IN
OSD Video
Signal Input
-
51 -
NU Not Used
-
52 OUT
OSD-V-
OUT
OSD Video
Signal Output
-
53 -
OSDVcc OSDVcc
-
54 -
HLF
LPF
Connected
Ter minal
(Slicer)
-
55
A,C -
NU Not Used
-
BIN
COLOR-
IN
SECAM or
MESECAM
Chroma Video
Input Signal at
Super Impose
-
56 -
NU Not Used
-
57 -
NU Not Used
-
58 IN
C-SYNC
Composite
Synchronized
Pulse
PULSE
59 OUT
8POUT-1
Control SCART
1 8Pin Level
by using
8POUT-1 and
8POUT-2
H/L
60 OUT
8POUT-2
Control SCART
1 8Pin Level
by using
8POUT-1 and
8POUT-2
Hi-z/L
61
A,C -
NU Not Used
-
BIN
SECAM-H
SECAM Mode
at High
-
62 -
NU Not Used
-
63 -
NU Not Used
-
64 -
NU Not Used
-
65
A,C -
NU Not Used
-
BOUT
TRICK-H
Special
playback = “H”
in SECAM
Mode
H
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
66 OUT
C-POW-
SW
Capstan Power
Switching
Signal
H/L
67 OUT
P-ON-H
Power On
Signal at High
H
68 OUT
DRV-
DATA
VFD Driver IC
Control Data
H/L
69 OUT
DRV-STB
VFD Driver IC
Chip Select
Signal
H/L
70 OUT
DRV-CLK
VFD Driver IC
Control Clock
H/L
71 OUT
IIC-BUS-
SCL
IIC BUS
Control Clock
H/L
72
IN/
OUT
IIC-BUS-
SDA
IIC BUS
Control Data
H/L
73 -
NU Not Used
-
74 -
NU Not Used
-
75 IN
DVD-
POWER-
MONITOR
DVD Power
Monitor Signal
(P-off=“L”, P-
on=“H”)
H/L
76 OUT
C-CONT
Capstan Motor
Control Signal
PWM
77 OUT
D-CONT
Drum Motor
Control Signal
PWM
78 OUT
C-F/R
Capstan Motor
FWD/REV
Control Signal
(FWD=“L”/
REV=“H”)
H/L
79 IN
S-REEL
Supply Reel
Rotation Signal
PULSE
80 IN
T- R E E L
Take Up Reel
Rotation Signal
PULSE
81 OUT
LM-FWD/
REV
Loading Motor
Control Signal
H/L/
Hi-z
82 OUT
OUTPUT-
SELECT
Output Select H/L
83 OUT
AUDIO-
MUTE-H
Audio Mute
Control Signal
(Mute = “H”)
H
84 -
NU Not Used
-
85 -
NU Not Used
-
86 IN
A-MODE
Hi-Fi Tape
Detection
Signal
L
87 IN
C-FG
Capstan Motor
Rotation
Detection
Pulse
PULSE
88 -
NU Not Used
-
89 -
NU Not Used
-
90
IN
D-PFG
Drum Motor
Phase/
Frequency
Generator
PULSE
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
