FUNAI DPVR-7630D - Electrical Parts List

20060407 1-19-1 E8B05EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DPVR-7630D A
DCVR-7830D B
DBVR-7730D C
Ref. No. Mark Description Part No.
A,C
B
DVD MAIN CBA UNIT
DVD MAIN CBA UNIT
N79GNKEP
N79GDKFP
Ref. No. Mark Description Part No.
A
B
C
MCV CBA
MCV CBA
MCV CBA
Consists of the following:
1VSA14456
1VSA14459
1VSA14463
C
MAIN CBA (MCV-A )
POWER SW CBA (MCV-B)
DVD OPEN/CLOSE CBA (MCV-C)
SENSOR CBA
----------
----------
----------
1VSA10047
Ref. No. Mark Description Part No.
MAIN CBA (MCV-A )
Consists of the following:
----------
CAPACITORS
C056 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
25V M
CE1EMASTM470
C057 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C058 ELECTROLYTIC CAP. 220µF/6.3V M H7
or
CE0KMASSL221
ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSM221
C059 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTM101
C062 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C063 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C104 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C107 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C109 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C112 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C113 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C114 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C116 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C117 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C118 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C121 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C122 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C123 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C124 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C125 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C126 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C127 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C128 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMASSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMASSM220
C133 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C135 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C136 ELECTROLYTIC CAP. 100µF/6.3V M H7
or
CE0KMASSL101
ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSM101
C251 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C252 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C253 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C301 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C302 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C306 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
