FUNAI DPVR-7630D - Mechanical Parts List

200560407 1-18-1 E8B05CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
DPVR-7630D A
DCVR-7830D B
DBVR-7730D C
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY H99A7ED 1VM221382A
A1X B FRONT ASSEMBLY H9907FD 1VM220783A
A1X C FRONT ASSEMBLY E8B30BD 1VM222364
A2 TOP CASE(D5 PAL FTZ) H9700ED 0VM101358
A3 CHASSIS E8B00ED 1VM221969
A7 BOTTOM PANEL H992URD 1VM321771
A10! A RATING LABEL E8B05ED ----------
A10! B RATING LABEL E8B06FD ----------
A10! C RATING LABEL E8B30BD ----------
A14 BARCODE LABEL UNFIGURE E9704ED ----------
A14 A BAR CODE LABEL E8B05ED ----------
A14 B BAR CODE LABEL E8B06FD ----------
A14 C BARCODE LABEL E8B30BD ----------
A22 CHASSIS FOOT H79P9JD 0VM412315
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
1B2 DVD MECHA E7 N79F0KVM N79F0KVM
2B2 TOP BRACKET H9700ED 0VM204531
2B3 RODER HOLDER H9600UD 0VM306676
2B5 SHEILD CYLINDER H9700ED 0VM306780
2B9 CUSHION HC460ED 0VM413251
2B16 TAPE HIMELON H9206JD 0VM413956
2B18 FIBER TOP CASE HC460ED 0VM412906
2B21 LASER CAUTION LABEL H9900ED ----------
2B40 PARTITION PLATE E8B00ED 1VM424064
2B54 PLATE GROUND(RCA) H9700ED 0VM306867
2B55 PLATE GROUND(21P) H9700ED 0VM416444
2L011 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L012 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L020 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L021 SCREW P-TIGHT M3*12 BIND+ GBJP3120
2L022 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L041 SCREW P-TIGHT 3X6 BIND HEAD+ GBCP3060
2L051 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L071 SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
2L091 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
L0-9 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
PACKING
S1 A GIFT BOX CARTON E8B05ED 1VM322939
S1 B GIFT BOX CARTON E8B06FD 1VM322940
S1 C GIFTBOX CARTON E8B30BD 1VM322917
S2 A,B STYROFOAM H9600UD 0VM204474E
S2 C STYROFOAM H9701BD 0VM204537
S3 UNIT BAG E5500UD 0VM411683
S7 21P PAD HC463FD 0VM413384
S9 C AC PAD HC461BD 0VM413331
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/
CZF05DD
NB126ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X5 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X20! B OWNERS MANUAL(FR) E8B06FD 1VMN22663
X20A! A OWNERS MANUAL(IT) E8B05ED 1VMN22665
X20A! C OWNERS MANUAL E8B30BD 1VMN22642
X20B! A OWNERS MANUAL(GE) E8B05ED 1VMN22664
X20B C QUICK GUIDE E8B01BD 1VMN22564
X22 A SERVICE CENTER LIST HC2C0ED 0VMN03071C
Ref. No. Mark Description Part No.
