FUNAI DPVR-7630D - Page 76

20060407 1-19-14 E8B05EL
AFV CBA
MISCELLANEOUS
JK1402 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JW003 FLAT CABLE 10P AWG26#2651/P2.0/190 WX3810S6FF19
JW004 FLAT CABLE 4P AWG26#2651/P2.0/190 WX3804S6FF19
Ref. No. Mark Description Part No.
A
B
C
AFV CBA
AFV CBA
AFV CBA
Consists of the following:
1VSA12950
1VSA12953
1VSA12531
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C4 CHIP CERAMIC CAP. CH J 56pF/ 50V CHD1JJ3CH560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C6 CHIP CERAMIC CAP. CH J 56pF/ 50V CHD1JJ3CH560
C7 CHIP CERAMIC CAP. CH C 3pF/ 50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/ 50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/ 50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/ 50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/ 50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/ 50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 or CE1JMASSL3R3
ALUMINUM ELECTROLYTIC CAP 3.3µF/
50V H7
CE1JMASSM3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C23 B CHIP CERAMIC CAP. F Z 0.47µF/10V or CHD1AZ30F474
B CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7
or
CE1JMASSLR22
ALUMINUM ELECTROLYTIC CAP
0.22µF/50V H7
CE1JMASSMR22
C26 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC1 A IC AUDIO PROCESSOR MSP3407G-
QG-B8-V3
NSZBA0SP3004
Ref. No. Mark Description Part No.
IC1 B,C IC AUDIO PROCESSOR MSP3417G-
QG-B8-V3
NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R2 B CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
B RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R4 CHIP RES. 1/10W J 120k Ω or RRXAJR5Z0124
RES CHIP 1608 1/10W J 120k Ω RRXA124YF002
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
R6 RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R7 B CHIP RES. 1/10W J 1.2k Ω RRXAJR5Z0122
R7 B RES CHIP 1608 1/10W J 1.2k Ω RRXA122YF002
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Mark Description Part No.
