FUNAI DRV-D2831 - Page 74

20050930 1-19-4 E9709EL
C1586 CHIP CERAMIC CAP.(1608) CH J 47pF/50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470
C1588 CHIP CERAMIC CAP.(1608) CH J 47pF/50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470
C1590 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1591 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1592 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1594 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1595 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ELECTROLYTIC CAP. 22µF/16V M CE1CMASTL220
C1597 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1598 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1599 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1601 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1602 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1605 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1606 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1607 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1609 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1612 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C1617 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C1618 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1619 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1620 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1621 CHIP CERAMIC CAP. CH J 39pF/50V or CHD1JJ3CH390
CHIP CERAMIC CAP. CG J 39pF/50V CHD1JJ3CG390
C1626 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C1627 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C1628 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1629 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1630 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1631 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1632 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1633 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1634 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1637 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1639 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1640 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1643 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTL470
C1648 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
Ref. No. Description Part No.
C1649 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1657 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1658 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1659 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1660 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1661 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1662 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1663 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C1664 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1665 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1671 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1672 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1673 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C1675 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C1681 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1684 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1685 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1686 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1687 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1688 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1689 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1691 CHIP CERAMIC CAP.(1608) CH J 47pF/50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470
C1692 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1693 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1694 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1695 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1696 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C1697 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1698 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7
C1699 CHIP CERAMIC CAP.(1608) CH J 47pF/50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470
C1700 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1701 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1702 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
CONNECTORS
CN1503 PH CONNECTOR TOP 2P B2B-PH-K-S or J3PHC02JG001
PH CONNECTOR (WHITE) TOP 2P B2B-PH-K-
S(LF)
J3PHC02JG017
CN1504 242 SERIES CONNECTOR 224202119W1 J322C19TG001
CN1505 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
CN1506 AFV PCB ASSEMBLY E9701AFV E9701AFV
DIODES
D301 SWITCHING DIODE 1N4148M or NDTZ01N4148M
Ref. No. Description Part No.
