FUNAI DRV-D2831 - Page 82

20050930 1-19-12 E9709EL
C2014 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
DIODES
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D014! SCHOTTKY BARRIER DIODE SB190 or NDQZ000SB190
! SCHOTTKY BARRIER DIODE SB190 NDWZ000SB190
D016 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D017 ZENER DIODE DZ-15BSCT265 or NDTC00DZ15BS
ZENER DIODE MTZJT-7715C QDTC00MTZJ15
D018 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D019 RECTIFIER DIODE FR203-B/P NDQZ000FR203
D1001 DIODE 1N5397-B NDLZ001N5397
D1002 DIODE 1N5397-B NDLZ001N5397
D1003 DIODE 1N5397-B NDLZ001N5397
D1004 DIODE 1N5397-B NDLZ001N5397
D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1011! RECTIFIER DIODE BA159 or NDQZ000BA159
! RECTIFIER DIODE BA159 NDWZ000BA159
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 RECTIFIER DIODE FR101 NDWZ000FR101
D1017 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1019! ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
! ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1023 PCB JUMPER D0.6-P5.0 JW5.0T
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1030 SCHOTTKY BARRIER DIODE SB240-B/P NDWZ000SB240
D1031! SCHOTTKY BARRIER DIODE SB390 or NDQZ000SB390
! SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D1032 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
ICS
IC1001! PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER EL817C or NPEC000EL817
! PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
! PHOTOCOUPLER LTV-817C-F or NPEC0LTV817F
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
COILS
L010 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L013 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1001 BEAD CORE ASSEMBLY E9700ED 1VSA11692
Ref. No. Description Part No.
L1002 BEAD CORE ASSEMBLY E9700ED 1VSA11692
L1003! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503 LLBG00ZKQ009
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1005 BEAD CORE ASSEMBLY E9700ED 1VSA11692
L1011 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1013 POWER INDUCTORS TWKBNP-180K or LLC180KKV007
INDUCTOR(18µH) CWKB-180K or LLC180KKV005
CHOKE COIL(18µH) LHL10NB180K LLARKGQTU180
TRANSISTORS
Q1001! FET 2SK3566 QFWZ02SK3566
Q1003! TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
! TRANSISTOR 2SC1815-Y(TPE2) QQSY02SC1815
Q1004 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR 2SA1175(J) or QQSJ02SA1175
TRANSISTOR 2SA1175(H) or QQSH02SA1175
TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(Y) or NQSY0KTA1267
TRANSISTOR KTA1267(GR) NQS10KTA1267
Q1008 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) or QQS102SC1815
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199 NQS40KTC3199
RESISTORS
R057 CHIP RES. 1/10W J 220k Ω RRXAJR5Z0224
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZQZ0823
METAL OXIDE FILM RES. 2W J 82k Ω RN02JZPZ0823
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1007 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1008 CARBON RES. 1/4W G 820 Ω RCX4GATZ0821
R1010 CARBON RES. 1/6W J 22k Ω or RCX6JATZ0223
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R1011 METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZLZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZQZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1021 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1022 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES. 1/10W F 2.2k Ω RRXAFR5Z0222
R1024 CHIP RES. 1/10W J 68k Ω RRXAJR5Z0683
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
Ref. No. Description Part No.
