4-2 FL13.8_DC
• The screw tightening torque must be 5.2lb·in
(6kgf·cm).
• Make sure the tact switches operate normally after
replacing the Front Cabinet, Function CBA Unit,
Sensor Lens, or Shield Plate.
• Make sure to replace the Control Plate to a new one
when replacing the Front Cabinet.
(S-3)
[2] Stand Assembly
(S-1)
(S-2)
[1] Rear Cover
(S-1)
Fig. D1
