4-3 FL13.8_DC
[4] Stand Holder
*
1
(S-4)
(S-4)
[3] Speaker
(S-4)
Fig. D2
*
1
: For 32ME303V/F7 (Serial No.:ME2), LF320EM4 (Serial No.:ME3), and
LF320EM4F (Serial No.: ME2) models, make sure to read all the precautions on page 4-1 when
you disassemble/re-assemble the Stand Holder.
Jack Holder
[5] Power Supply CBA
(S-5)
(S-6)
[6] Digital Main CBA Unit
Fig. D3
