8-16
WF1
PIN14 OF
IC801
WF2
PIN23 OF
CN101A
WF3
PIN25 OF
CN101A
WF5
PIN4 OF
CN102A
WF4
PIN5 OF
CN102A
WF6
PIN3 OF
CN102A
WF7
PIN1 OF
CN102A
Main CBA Bottom View
BA8C72F01012-1
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
Because a hot chassis ground is present in the power
supply circut, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly, when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
