FUNAI LT6-M22BB - Electrical Parts List

20081020 13-1 A8C72/73EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DIGITAL MAIN CBA UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
LT6-M22BB A
LT6-M22WB B
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT 1ESA19428
Ref. No. Mark Description Part No.
A
B
MMA CBA
MMA CBA
Consists of the following:
1ESA18405
1ESA18486
MAIN CBA
FUNCTION CBA
IR SENSOR CBA
JACK CBA
----------
----------
----------
----------
Ref. No. Mark Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C102 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C103 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C104 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C508 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C510 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C512 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C513 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C516 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C517 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C518 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C519 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C520 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C524 ELECTROLYTIC CAP. 33µF/16V M H7 CE1CMAVSL330
C525 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C600! METALIZED FILM CAP. 0.22µF/250V or CT2E224MS037
! CAP METALIZED FILM 0.22µF/300V K
3.5MM
CT2F224DC004
C601! METALIZED FILM CAP. 0.1µF/250V or CT2E104MS037
! CAP METALIZED FILM 0.1µF/300V K
3.5MM
CT2F104DC004
C615! CAP ELECTROLYTIC 180µF/400V M CA2H181DYG10
C621 CERAMIC CAP. 470pF/2KV or CA3D471PAN04
CERAMIC CAP. BL 470pF/2KV CA3D471XF003
C623 POLYESTER FILM CAP. (PB FREE)
0.01µF/100V J or
CA2A103DT018
CAP POLYESTER FILM 0.01µF/100V J CA2A103SER02
C624 POLYESTER FILM CAP. (PB FREE)
0.0015µF/100V J or
CA2A152DT018
CAP POLYESTER FILM 0.0015µF/100V J CA2A152SER02
C625 POLYESTER FILM CAP. (PB FREE)
0.068µF/100V J or
CA2A683DT018
CAP POLYESTER FILM 0.068µF/100V J CA2A683SER02
C630! SAFTY CAP. 1000pF/250V KX or CA2E102MR101
! SAFETY CAP. 1000pF/250V KX or CA2E102MR050
! CAP CERAMIC 1000pF/250V/M CA2E102MR086
C642! SAFETY CAP. 2200pF/250V KX or CA2E222MR050
! SAFTY CAP. 2200pF/250V KX or CA2E222MR101
! CAP CERAMIC 2200pF/250V/M CA2E222MR086
C702 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C703 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C707 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C710 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C711 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C712 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C714 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C716 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C718 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C720 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C721 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C722 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C723 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C731 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C732 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C733 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C734 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C741 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C742 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C744 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C745 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C747 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C751 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C753 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C756 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C758 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C788 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C789 ELECTROLYTIC CAP. 330µF/6.3V M H7 CE0KMAVSL331
C791 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C792 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C793 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C794 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
Ref. No. Mark Description Part No.
