FUNAI LT6-M22BB - Mechanical Parts List

20081020 12-1 A8C72/73CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
LT6-M22BB A
LT6-M22WB B
Ref. No. Mark Description Part No.
A1 A FRONT CABINET A8C70EP 1EM022865A
A1 B FRONT CABINET A8C71EP 1EM023145A
A4 A REAR CABINET A8C72EP 1EM023147B
A4 B REAR CABINET A8C73EP 1EM023265B
A5 A DECORATION PLATE A8A70UH 1EM222263
A5 B DECORATION PLATE A8C71EP 1EM222643
A7 A FUNCTION KNOB A8CN0FP 1EM222143A
A7 B FUNCTION KNOB A8CN3FP 1EM324537A
A9 A STAND COVER A8CN0FP 1EM022467
A9 B STAND COVER A8CN3FP 1EM222443
A10 A REAR COVER A73F0EP 1EM322722
A10 B REAR COVER A8C71EP 1EM325157A
A11 SENSOR LED LENS A8CN0FP 1EM323959
A12 STAND RUBBER FOOT A8AN0UH 1EM426377
A24 A NECK COVER A8A70UH 1EM325318
A24 B NECK COVER A8C71EP 1EM325159
B1 SPEAKER HOLDER A7120UH 1EM423986
B3 WALL MOUNT BRACKET A84N0UH 1EM323797
B8 SHIELD BOX A8CN0FP 1EM122473
B9 SHIELD (T) A8CN6EP 1EM325219
B10 FFC SHIELD A8CN6EP 1EM427320
B15 STAND HINGE A8C70EP 1EM325037
B29 CLOTH(10X30XT0.5) B5900UA 0EM404486
B32 CLOTH(15X40XT0.5) A7140UH 1EM424366
B36 GASKET A8AF0UH 1EM425861
B47 CLOTH(10X40XT1) A8A70UH 1EM427377
CL107 WIRE ASSEMBLY 7PIN WX1A8CN0-012 WX1A8CN0-012
CL451 WIRE ASSEMBLY 2PIN WX1A8C70-002 WX1A8C70-002
CL802 WIRE ASSEMBLY 2PIN WX1A8C70-002 WX1A8C70-002
CL3601 WIRE ASSEMBLY 25PIN WX1A8CN0-
006
WX1A8CN0-006
CL3701 WIRE ASSEMBLY 25PIN WX1A8CN0-
006
WX1A8CN0-006
CL3704 WIRE ASSEMBLY 23PIN WX1A8CN0-
005
WX1A8CN0-005
CL4501 WIRE ASSEMBLY FFC 55PIN FFC WIRE/
55PIN/42MM
WX1A8A70-101
CL4502 WIRE ASSEMBLY FFC 55PIN FFC WIRE/
55PIN/42MM
WX1A8A70-101
CL4503 FFC WIRE 25PIN WX1A8C70-005 WX1A8C70-005
CN3802 CONNECTOR IC CARD OSU SLOT
2013858-1
J620680AP001
L2 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L17 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L28 HEX SCREW #4-40 7MM 1EM422042
L29 DOUBLE SEMS SCREW M2X10+
M2X10
FPJ32100
L30 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
L36 DOUBLE SEMS SCREW M2X6+ M2X6 FPJ32060
LCD1 LCD MODULE 22INCH WIDE CMO
22INCH WSXGA+
UG220EA
SP451 SPEAKER S0407F10 or DSD0807XQ002
SPEAKER MAGNETIC YDP47-1FN DSD0807EFU01
SP802 SPEAKER S0407F10 or DSD0807XQ002
SPEAKER MAGNETIC YDP47-1FN DSD0807EFU01
PACKING
S4 SET BAG A81N0UH 1EM322872A
S6 STAND BAG A81N0UH 1EM424597
ACCESSORIES
X3 A REMOTE CONTROL NF028RD 170/
ECPLC6.501/NF028
NF028RD
X3 B REMOTE CONTROL NF031RD 170/
ECPLC6.501/NF031
NF031RD
Ref. No. Mark Description Part No.
A6! A RATING LABEL A8C72EP ----------
A6! B RATING LABEL A8C73EP ----------
A21 POP LABEL A8CN1EP ----------
A27 CARD LABEL A8CN0FP ----------
B35 WASHER(D12) A8C70EP 1EM427237
B43 RUBBER CUSHION (10X15X10)
A71F3UH
1EM424529
L4 SCREW P-TIGHT 3X12 BIND HEAD+
BLK
GBHP3120
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L11 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L17 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L30 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
L32 SCREW P-TIGHT D4X10 BIND HEAD+ GBJP4100
PACKING
S1 A CARTON A8C70EP 1EM325099A
S1 B CARTON A8C71EP 1EM427439A
S2 STYROFOAM TOP A8C70EP 1EM022885A
S3 STYROFOAM BOTTOM A8C70EP 1EM022886A
S5 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X4 BATTERY R6DB/2PA XB0M601MS003
X2-1! OWNERS MANUAL(DE-6) DE IT EL SV
FR EN
1EMN23923
X2-2! OWNERS MANUAL(FR-6) FR ES PT IT
DE NL
1EMN23924
X2-3! OWNERS MANUAL(PL-6) PL DE HU RO
CS SK
1EMN23925
! OWNER'S MANUAL(AR) 1EMN23926
! OWNER'S MANUAL(BG) 1EMN23927
! OWNER'S MANUAL(EN) 1EMN23928
! OWNER'S MANUAL(RU) 1EMN23929
! OWNER'S MANUAL(UA) 1EMN23930
Ref. No. Mark Description Part No.
