20081020 13-7 A8C72/73EL
FUNCTION CBA
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R947 CARBON RES. 1/4W J 47k Ω RCX4JATZ0473
R948 METAL RESISTER. 2W J 0.82 Ω or RN02R82ZU001
METAL OXIDE FILM RES. 2W J 0.82 Ω RN02R82DP004
R949 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R950 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R953 METAL OXIDE FILM RES. 2W J 47 Ω or RN02470ZU001
METAL OXIDE FILM RES. 2W J 47 Ω RN02470DP004
R954 METAL OXIDE FILM RES. 2W J 12 Ω or RN02120ZU001
METAL OXIDE FILM RES. 2W J 12 Ω RN02120DP004
R955 METAL OXIDE FILM RES. 2W J 47 Ω or RN02470ZU001
METAL OXIDE FILM RES. 2W J 47 Ω RN02470DP004
R958 PCB JUMPER D0.6-P5.0 JW5.0T
R959 CHIP RES. 1/10W F 12k Ω or RRXAFR5H1202
CHIP RES.(1608) 1/10W F 12k Ω or RRXAFR5Z1202
RES CHIP 1608 1/10W F 12.0k Ω RTW1202YF002
R960 CHIP RES. 1/10W F 620 Ω or RRXAFR5H6200
CHIP RES. 1/10W F 620 Ω or RRXAFR5Z6200
RES CHIP 1608 1/10W F 620 Ω RTW6200YF002
R961 CHIP RES. 1/10W F 3k Ω or RRXAFR5H3001
CHIP RES. 1/10W F 3.0k Ω or RRXAFR5Z3001
RES CHIP 1608 1/10W F 3.00k Ω RTW3001YF002
R962 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R963 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002
R964 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R965 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R966 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R967 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R968 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R969 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R970 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R971 CHIP RES. 1/10W F 8.2k Ω or RRXAFR5H8201
CHIP RES. 1/10W F 8.2k Ω or RRXAFR5Z0822
RES CHIP 1608 1/10W F 8.20k Ω RTW8201YF002
R972 CHIP RES. 1/10W F 5.1k Ω or RRXAFR5H5101
CHIP RES. 1/10W F 5.1k Ω or RRXAFR5Z0512
RES CHIP 1608 1/10W F 5.10k Ω RTW5101YF002
R973 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R974 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
R976 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H5601
CHIP RES. 1/10W F 5.6k Ω or RRXAFR5Z0562
RES CHIP 1608 1/10W F 5.60k Ω RTW5601YF002
R977 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002
R978 CHIP RES. 1/10W J 8.2k Ω or RRXAJR5Z0822
RES CHIP 1608 1/10W J 8.2k Ω RRXA822YF002
R979 METAL OXIDE FILM RES. 1W J 270 Ω or RN01271DP003
METAL OXIDE FILM RES. 1W J 270 Ω RN01271ZU001
R980 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R982 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H5601
CHIP RES. 1/10W F 5.6k Ω or RRXAFR5Z0562
RES CHIP 1608 1/10W F 5.60k Ω RTW5601YF002
R983 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002
R985 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R986! CHIP RES. 1/10W F 240 Ω or RRXAFR5H2400
! CHIP RES.(1608) 1/10W F 240 Ω or RRXAFR5Z2400
! RES CHIP 1608 1/10W F 240 Ω RTW2400YF002
R987 CHIP RES. 1/10W J 100 Ω or RRXAJR5Z0101
RES CHIP 1608 1/10W J 100 Ω RRXA101YF002
Ref. No. Mark Description Part No.
R992 PCB JUMPER D0.6-P5.0 JW5.0T
R994 CHIP RES. 1/10W F 3.3k Ω or RRXAFR5H3301
CHIP RES.(1608) 1/10W F 3.3k Ω or RRXAFR5Z3301
RES CHIP 1608 1/10W F 3.30k Ω RTW3301YF002
R995 CHIP RES. 1/10W F 43.0 k Ω or RRXAFR5H4302
RES CHIP 1608 1/10W F 43k Ω or RRXAFR5Z4302
RES CHIP 1608 1/10W F 43.0k Ω RTW4302YF002
R997 METAL OXIDE FILM RES. 2W J 0.22 Ω or RN02R22ZU001
METAL OXIDE FILM RES. 2W J 0.22 Ω RN02R22DP004
MISCELLANEOUS
AC601! A AC CORD PE8G2CG9G0A-059 or WAE0172LW010
! A AC CORD P205-1503-2 WAE0172K5001
AC601! B AC CORD PE8G2CG9G9D-059 or WAE9172LW002
! B AC CORD P205-1517-2 WAE9172K5001
B22 HEAT SINK PMS ASSEMBLY A8CN0FP 1EM426337A
B41 HEAT SINK PMT ASSEMBLY A8C70EP 1EM426357
B42 HEAT SINK PMW A8C70EP 1EM426760
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC603 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC750 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 PCB JUMPER D0.6-P5.0 JW5.0T
BC802 PCB JUMPER D0.6-P5.0 JW5.0T
BC803 PCB JUMPER D0.6-P5.0 JW5.0T
BC804 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC805 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC903 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
F601! FUSE 4A/250V(PB FREE) 0215004.MXP PBGZ20BAG021
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JK721 JACK SW DIN PCB S 04/DIN-417HA-01
or
JYEJ040YUQ03
JACK SW DIN PCB S 04 MDC-076H-A LF JYEJ040LY002
JK722 JACK RCA PCB S YELLOW 01/RCA-
101H(YL) or
JXRJ010YUQ05
JACK RCA PCB S (YELLOW) 01 MTJ-
032-04B-40 FE
JXRJ010LY032
JK723 JACK RCA PCB S WHITE 01/RCA-
101H(WH) or
JXRJ010YUQ02
JACK RCA PCB S (WHITE) 01 MTJ-032-
04B-41 FE
JXRJ010LY031
JK724 JACK SW RCA PCB S RED RCA-
102H(RD) or
JYRJ010YUQ03
JACK SW RCA PCB S(RED) 01 MTJ-032-
04A-75 FE
JYRJ010LY031
JK725 JACK HPEP SML PCB S PJ-358H or JXSJ020YUQ01
JACK HPEP SML PCB S 02 MSJ-035-
29D (ABS)
JXSJ020LY001
JK751 JACK RGB PCB S 21PIN / MRC-021H-02 JXGJ210LY001
JK801 JACK SE HPEP SML PCM S MSJ-035-
04A LF or
JYSJ020LY002
JACK SW HPEP SML PCB S PJ-362H-7 JYSJ020YUQ02
L9 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601! SURGE ABSORBER 470V+-10PER or NVQZ10D471KB
! VARISTOR 10D 471K SVR NVQZVR10D471
T601! SW-TRANS 8719 or LTT3PE0KT046
! SW-TRANS BCK-35-0554 LTT3PE0XB040
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
Ref. No. Mark Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITORS
C201 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C202 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
Ref. No. Mark Description Part No.
To Next Page
