FUNAI LT6-M22BB - Page 63

20081020 13-12 A8C72/73EL
JUNCTION CBA
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R489 CHIP RES. 1/10W F 7.50 k Ω or RRXAFR5H7501
CHIP RES. 1/10W F 7.5k Ω or RRXAFR5Z7501
RES CHIP 1608 1/10W F 7.50k Ω RTW7501YF002
R490 CHIP RES. 1/10W F 8.2k Ω or RRXAFR5H8201
CHIP RES.(1608) 1/10W F 8.2k Ω or RRXAFR5Z8201
RES CHIP 1608 1/10W F 8.20k Ω RTW8201YF002
R491 CHIP RES. 1/10W J 12k Ω or RRXAJR5Z0123
RES CHIP 1608 1/10W J 12k Ω RRXA123YF002
R492 CHIP RES. 1/10W J 10 Ω or RRXAJR5Z0100
RES CHIP 1608 1/10W J 10 Ω RRXA100YF002
R493 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R494 CHIP RES. 1/10W J 12k Ω or RRXAJR5Z0123
RES CHIP 1608 1/10W J 12k Ω RRXA123YF002
R495 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R496 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R497 PCB JUMPER D0.6-P5.0 JW5.0T
R498 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R499 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R500 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R501 CHIP RES. 1/10W J 10 Ω or RRXAJR5Z0100
RES CHIP 1608 1/10W J 10 Ω RRXA100YF002
R502 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R503 CHIP RES. 1/10W J 12k Ω or RRXAJR5Z0123
RES CHIP 1608 1/10W J 12k Ω RRXA123YF002
R504 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R506 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R507 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R508 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R509 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R510 CHIP RES. 1/10W J 8.2k Ω or RRXAJR5Z0822
RES CHIP 1608 1/10W J 8.2k Ω RRXA822YF002
R511 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R514 CHIP RES.(1608) 1/10W F 22k Ω or RRXAFR5H0223
CHIP RES. 1/10W F 22k Ω or RRXAFR5Z0223
RES CHIP 1608 1/10W F 22.0k Ω RTW2202YF002
MISCELLANEOUS
F401 CHIP FUSE FHC32322ADTP PDDFTC0KE322
J431 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JS401 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JS402 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
T401 TRANS INVERTER TK.7604A.101 LTZ3PZDAR004
T402 TRANS INVERTER TK.7604A.101 LTZ3PZDAR004
T403 TRANS INVERTER TK.7604A.101 LTZ3PZDAR004
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN404A WIRE ASSEMBLY 14PIN 14PIN/68MM WX1A8A70-003
MISCELLANEOUS
CL404 242 SERIES CONNECTOR TUC-P14X-B1 WHT
ST
JCTUB14TG002
Ref. No. Description Part No.
TU501! TUNER UNIT DTV TDAG4-B04A UTUNPSGAL013
Ref. No. Description Part No.
