Up-count / down-count of
numbers
For entering numbers a virtual
keypad. Enterings have to be
accomplished always with
↵
4.1.Connections
1) USB B port for connections with a PC
The device is setup as an serial device.
2) USB A port for USB-mass storage
USB-Sticks formatted preferably with FAT file system can
be connected. Usage of USB-hard-disks is not
recommended.
3) Ethernet-port
4) serial port for extensions
5) serial port for printer
The baud rate is 9600 Baud/s with 8N1 setting.
Main connection
The device can be connected to an AC Power source with
84 to 264 volts
7
