FUNKY MONKEY BARS Boxing Bag - Resistance Bands Assembly; Inventory Check; Select Location for Band Add-on

2x
Short Tee
D-101
1x
Purple Resistance Band
1040mm Long x 45mm Wide
Strength: 22-57kg
1x
Green Resistance Band
1040mm Long x 64mm Wide
Strength: 30-80kg
1x
Blue Resistance Band
1040mm Long x 83mm Wide
Strength: 36-105kg
50Dia. x 120mm
2x
Band Tube
FITTINGS, HARDWARE & TUBES
A
2x
Plastic End Cap
The resistance band add-on kit requires
a pull up bar or gym bar for installation.
Your gym bar may be attached to an adjustable
leg tube ‘A’ (shown) or a swing leg.
Select height for resistance bands.
ASSEMBLY INSTRUCTIONS - RESISTANCE BANDS
1
CHECK INVENTORY - (not to scale)
Check that you have the following
items before assembling your
Funky Monkey Bars® Resistance Bands.
Page 17
Gym Bar
SELECT DESIRED LOCATION OF RESISTANCE BAND ADD-ON
2
