Furius FIX 201 - Display; Explanation of Symbols in the Front Panel

15
Symbol
Description
Warning! Read the user
manual.
Temperature protection
indicator (yellow led).
Machine power indicator
(green led)
Amps
1) Machine protection and power indicator .
2) LED display.
3) Current adjustment knob.
Explanation of symbols in the front panel
For the explanation of the symbols shown on the front panel of the machine, refer to the following
table:
