SET METER BRIGHTNESS
Sets the LCD display and outlet bank indicator brightness.
Send to UPS: !SET_BRIGHT xxx<CR>
Where:
xxx = {100, 075, 050, 025}
If specified brightness setting is invalid
Action: No action will be taken, UPS will report INVALID_PARAMETER and
display current state of mode argument.
Response from UPS: $INVALID_PARAMETER<CR>
$BRIGHTNESS = xxx<CR>
SET DISPLAY SCROLL MODE
Sets the LCD display SCROLL mode
Send to UPS: !SET_SCROLLMODE xxx<CR>
Where:
xxx = {5SEC, 10SEC, OFF}
If specified display scroll mode is invalid
Action: No action will be taken, UPS will report INVALID_PARAMETER and
display current state of mode argument
Response from UPS: $INVALID_PARAMETER<CR>
$SCROLL_MODE = xxx<CR>
SET DISPLAY SLEEP MODE
Sets the inactivity timeout period after which the display will enter into its low-
est brightness mode.
Send to UPS: !SET_SLEEPMODE xxx<CR>
Where:
xxx = {30SEC, 60SEC, OFF}
If specified display sleep mode is invalid
Action: No action will be taken, UPS will report INVALID_PARAMETER and
display current state of mode argument
Response from UPS: $INVALID_PARAMETER<CR>
$SLEEP_MODE = xxx<CR>
RESET FACTORY SETTINGS
Resets all of the custom configuration settings
Send to UPS: !RESET_ALL<CR>
Action: Sets all state variables to the default values
Response from UPS: $FACTORY SETTINGS RESTORED<CR>
OUTLET STATUS
Requests the ON/OFF status of the outlet banks
Send Query to UPS: ?OUTLETSTAT<CR>
status = {ON, OFF}
Action: ON/OFF status for outlets will be provided.
Response: $BANK1 = status<CR>
$BANK2 = status<CR>
$BANK3 = status<CR>
$BANK4 = status<CR>
POWER STATUS
Requests the status of the input voltage. The responses are the same as
Power Fault Status Change.
Send Query to UPS: ?POWERSTAT<CR>
Action: Power status messages will be returned
Response: Normal operation = $PWR = NORMAL<CR>
Overvoltage $PWR = OVERVOLTAGE<CR>
Undervoltage $PWR = UNDERVOLTAGE<CR>
Lost Power $PWR = LOST POWER<CR>
Test Mode $PWR = TEST<CR>
POWER
Requests the input and output voltages
Send Query to UPS: ?POWER<CR>
Action: Voltage status messages will be displayed
Response: $VOLTS_IN = vvv<CR>
$VOLTS_OUT = vvv<CR>
$WATTS = xxxx<CR>
$CURRENT = xx.x<CR>
(xxx is expressed in decimal format)
If the value is less than 100, the hundreds digit is represented with a 0.
For example a line voltage of 234VAC would be expressed as:
$VOLTAGE = 234<CR>
POWER CYCLE COMMAND USING TELNET PROTOCOL with BlueBOLT-CV1
#CYCLE Turns an outlet off, then delays before turning it back on.
(NOTE - THIS COMMAND IS ONLY AVAILABLE WHEN USING THE TELNET PROTO-
COL WITH THE BlueBOLT-CV1 INTERFACE. IT IS NOT SUPPORTED OVER SERIAL
(RS-232) CONNECTION).
Send to UPS (CV-1 card): #CYCLE bank:delay<CR>
bank = {1, 2, 3, 4}, delay = {1-65536}
Action: Turns off specified outlet bank them waits for delay seconds and finally
turns the outlet bank back on.
Response: There are no direct responses from this command, but the outlet
status change messages will be sent as the outlet changes state:
$OUTLETn = status Where n = {1-4} Status = {ON, OFF}
CONTROLLER QUERIES:_____________________________________
SEND QUERIES IDENTIFY
Request that the unit identify itself.
Send Query to UPS: ?ID<CR>
Action: Model number and firmware revision will be provided.
Response: $FURMAN<CR>
$F1500-UPS E<CR>
$firmware revision<CR>
