Nominal Line Voltage: 220 VAC 230 VAC 240 VAC
UPS INPUT
Voltage 156-274 VAC 166-284 VAC 176-294 VAC
Line Frequency 50/60 Hz +/- 3% (auto sensing)
UPS OUTPUT
Voltage: 220 VAC +/- 10% 230 VAC+/- 10% 240 VAC+/- 10%
Frequency 50/60 Hz +/- 1% (adaptive)
Current Rating 6.82 A 6.53 A 6.25 A
UPS Output Capacity 1500 VA, 900W, cos 0.6
UPS Backup Time 12 minutes at full load, 32 minutes at half load
UPS Transfer Time < 4ms
AUTOMATIC VOLTAGE REGULATION
Standard Mode Capture Range 160-276 VAC 170-286 VAC 180-296 VAC
Standard Mode Output Range 220 +/- 28 VAC 230 +/- 28 VAC 240 +/- 28 VAC
Sensitive Mode Capture Range 173-257 VAC 181-268 VAC 188-280 VAC
Sensitive Mode Output Range 220 +/- 15 VAC 230 +/- 15 VAC 240 +/- 15 VAC
SURGE PROTECTION
Technology Non-sacrificial SMP (Series Multi-Stage Protection)
Overvoltage Shutoff, fast rise: 305 VAC
Overvoltage Shutoff, slow rise: 265 VAC 275 VAC 285 VAC
Noise Attenuation: INPUT 10 dB @ 10kHz, 40 dB @ 100 kHz, 50 dB @ 500kHz
Linear Attenuation Curve: From 0.05 - 100 Ohms line impedance
UPS PHYSICAL ATTRIBUTES
UPS Topology Line Interactive
Temperature Rating 0 ~ 40°C / 40°C maximum for ambient operation
Mass 32.5 Kg / 72 lbs.
Dimensions 89mm H x 487.7mm L x 444.5mm D / 3.5” H x 19.2” L x 17” W
Battery Sealed Lead-Acid
Plug 1mm
2
x 3.3m, Detachable male Schuko with retention clips
Display Alphanumeric 2 X 20 LCD STN positive image, Backlit blue
Specifications
