1. RADAR OPERA
TION
1-20
Stern-up mode
The stern-up mode rotates the head-up mode
picture, relative and true bearings
and display graphics 180°. This mode is
useful on dual-radar tugboat
s when
backing up; one radar shows head-up and
another shows stern-up. T
o enable
the stern-up mode, turn on STE
RN-UP on the 7 OPERA
TION menu.
Heading Line
North Marker
S
tern-up mode
43
