1. RADAR OPERATION
1-65
[PICTURE MENU]
1 INT REJECT
OFF/1/2/3
2 ECHO STRETCH
OFF/1/2/3
3 ECHO AVERAGE
OFF/1/2/3
4 NOISE REJ
OFF/ON
5 AUTO STC
OFF/ON
6 AUTO RAIN
OFF/1/2/3/4
7 VIDEO CONTRAST
1/2/3/4/
A/B/C
8 [PULSE]
9 [CONDITION]
0 DEFAULT
NO/SAVE/USER/
FACTORY
1.35.1 Selecting a picture setup option
You may select a picture setup options as follows:
Left-click PICTURE box at the left side of the screen to select picture setup
option desired.
NEAR BUOY* 
* Other possible indications:
NEAR, FAR, FAR BUOY,
ROUGH SEA, SHIP,
HARBOR, COAST, ICE
PICTURE 1 - PICTURE 3
1.35.2 Programming and saving picture setups
User-programmable picture setups and they are provided in the PICTURE box.
Normally, PICTURE1-PICTURE3 are for programming but you may program any
other picture item as desired. You may program and save them as below.
1. Left-click the PICTURE box at the left side of the screen to select the item to
program.
2. Push the right button to show the PICTURE menu.
PICTURE menu
