1. OPERATIONAL OVERVIEW
1-14
*
1
: Shown on A/B/W-types only
*
2
: Shown on B/W-types only
*
3
: Shown on A/B/W-types only when [5 AUTO TARGET TRACK], located in [2
MARKS] ([2 MARKS•CHARTS] for systems with Radar Plotter functionality) → [7
TRACKS] → [3 TARGET TRACK] menu, is set to [OFF].
1.8 Cursor Data
The cursor data display shows the cursor’s latitude and longitude position or the cur-
sor’s X-Y co-ordinates.
Place the cursor on the [CURSOR DATA] box at the top-right side of the display then
press the left button to switch between display formats.
The data box shows the cursor location, bearing/range to the cursor location and the
time to go (TTG) to the cursor location.
Note 1: For the X-Y co-ordinates display, the Y-axis is the upper/lower half of the
screen, the upper half of the screen is “plus” and the lower part of the screen is “mi-
nus”. The X-axis is the left/right-side of the screen, right is “plus”, left is “minus”.
Note 2: Cursor data reads "- - -.-" when the cursor is placed outside the operational
display area.
Page 2
TARGET DATA / ACQ SETTING Change target tracking settings.
TARGET CANCEL SETTING Change target cancel settings.
RANGE RINGS Show/hide the range rings.
SLEEP ALL TARGETS Sleep all AIS targets.
Menu Item Description
33°59.156’N
135°06.328’E
X: +1.667NM
Y: +3.694NM
TTG 00:05
33°59.156’N
135°06.328’E
0.24.4ºR
4.028NM
TTG 00:05
Bearing/range
displayed
Cursor’s X-Y
co-ordinates
displayed
Press the left button
to switch between
display formats
Press the left button
to switch between
display formats
TTG to cursor position
Bearing/range to
cursor position.
X/Y axis
coordinates
to cursor
position.
Cursor positon’s
latitude/longitude
To Next Page
