Furuno FCV-585 - System Configuration Diagrams

vi
SYSTEM CONFIGURATION
FCV-620
FCV-585
DISPLAY UNIT
CV-620
: Standard
: Option
Power supply
12-24 VDC
: Local Supp
ly
Water temperature/speed sensor
ST-02MSB, ST-02PSB
Water temperature sensor
T-02MSB, T-02MTB, T-03MSB
GPS Navigator
or
Water temperature sensor
Transducer
5
20-5PSD, 520-5MSD, 525-5PWD,
525ST-MSD, 525ST-PWD
: Standard
: Option
Power supply
12-24 VDC
: Local Supply
Water temperature/speed sensor
ST-02MSB, ST-02PSB
Water temperature sensor
T-02MSB, T-02MTB, T-03MSB
GPS Navigator
or
Water temperature sensor
Transducer
520-5PSD, 520-5MSD, 525-5PWD,
525ST-MSD, 525ST-PWD
Matching Box
MB-1100*
*: For connection to 1 kW transducer
(50B-6, 50B-6B, 200B-5S, 50/200-1T)
DISPLAY UNIT
CV-585
