2-11
[1] [2] [3]
m ft fa PB
kt MPH KPH
° C ° F
OFF ON
WEAK MED STRG
GRPH DATA
( * SYSTEM MENU [1] *)
MENU :
DEPTH :
SPEED :
TEMP :
ZOOM MARK :
F/A LEVEL :
NAV :
[1] [2] [3]
15 (10 - 1000)
30
60
120
200
400
600
1000
X2 X3 X4 X5
10 20
(* SYSTEM MENU [3] *)
MENU :
RANGE1 :
RANGE2 :
RANGE3 :
RANGE4 :
RANGE5 :
RANGE6 :
RANGE7 :
RANGE8 :
ZOOM RANGE:
B/L RANGE:
/ : TO SELECT ITEM.
-/+ : TO SET CONDITION.
/ : TO SELECT ITEM.
-/+ : TO SET CONDITION.
[1] [2] [3]
OFF L/L R/B CSE
NMEA CIF
OFF OWN NMEA
OFF OWN NMEA
OFF LOW HIGH
+0 % [-50 - +50]
+0.0 °F [-20 - +20]
(* SYSTEM MENU [2] *)
(ADJUSTABLE OWN SENSOR ONLY.)
OWN SENSOR
TEMPERATURE
MENU :
NAV DSP :
FORMAT :
SPD SEL :
TMP SEL :
TMP GRP:
SPD ADJ :
TMP ADJ :
/ : TO SELECT ITEM.
-/+
: TO SET CONDITION.
OWN SENSOR
SPEED
0.0 kt °F
4. Press [▲] or [▼] to select menu item.
5. Press [+] or [-] to set condition.
6. Set the [MODE] switch in any other position to register selection and close the menu.
2.11.2 Main menu description
Menu item Description
NOISE LIMITER Eliminates noise from other echo sounders and electrical
interference.
HUE SELECTION Selects colors for echoes and background.
GAIN ADJUST (50kHZ, 200KHZ) Adjusts the gain for both high and low frequencies. Changing
this setting by 10 is equal to changing the GAIN control by 1. If
the sensitivity is too low or the auto function does not work
properly when the transducer is installed inside the hull, try to
adjust the gain here.
CLUTTER LEVEL Eliminates blue dots, which are mainly caused by unclean
water, from the screen.
ZOOM MODE Selects the type of zoom display. B/L, Bottom-lock; B/Z,
Bottom zoom, and M/Z, Marker zoom.
MARKER Selects which marker to use; VRM or white marker.
GO TO SYSTEM MENU Select YES to go to the system menu.
To Next Page
