Furuno MARINERADAR FR-8122 User Manual

SYSTEM CONFIGURATION
xii
FR-8122, FR-8062
ANTENNA UNIT
RSB-0073-085-XN12A/XN13A: FR-8062
RSB-0073-086-XN12A/XN13A: FR-8122
DISPLAY UNIT
RDP-150
Rectifier
RU-3423
100/110/
115/220/
230 VAC, 1
φ
12-24 VDC
Remote
Display
Commercial Monitor
(SVGA or better)
Gyro
Converter
AD-100
Heading Sensor
PG-1000
NMEA
Device
NMEA
Device
External
Buzzer
OP03-136
: Optional equipment
Gyrocompass
Remote
Controller
RCU-019
OR
Auto Plotter
ARP-11
(built into
display unit)
RGB
Category of units
Antenna unit: Exposed to weather
All other units: Protected from weather

Furuno MARINERADAR FR-8122 Specifications

General

Brand	Furuno
Model	MARINERADAR FR-8122
Category	Marine Radar
Language	English
