Furuno MODEL 1622 - SYSTEM CONFIGURATION; ANTENNA UNIT; DISPLAY UNIT

iv
SYSTEM CONFIGURATION
SIGNAL CABLE (Select one.)
MJ-A10SPF0003-050 (5 m)
MJ-A10SPF0003-100 (10 m)
MJ-A10SPF0003-150 (15 m)
MJ-A10SPF0003-200 (20 m)
03S9175 (30 m, option for 24 VDC only)
ANTENNA UNIT
RSB-0060
DISPLAY
UNIT
RDP-125
NMEA 0183 Cable
MJ-A6SPF0012-050 (5 m)
MJ-A6SPF0012-100 (10 m)
NAVIGATOR
(NMEA 0183)
EXTERNAL
BUZZER
OP03-136
POWER CABLE
MJ-A3SPF0013-035
SHIP'S MAINS
12/24 VDC
Options shown with
dashed lines.
SOUNDER
(1 m)
RECTIFIER
PR-62
SHIP'S MAINS
100/110/115/220/230 VAC
RADAR REMOTE
DISPLAY
FMD-1712
SIGNAL CABLE ASSY.
MJ-A10SPF0008-XXX
(supplied with FMD-1712)
