4. RC1815/RC1825 Equipment Installations

4-6

4.4 FS-1570/FS-2570 Installation (Continued)

Refer to Installation Manual, FS-1570 (150W) / FS-2570 (250W)

4.4.5 DSC/Watch Receiver Antenna (Continued)

4) Reassemble the transceiver.

4.4.6 NMEA/IEC-61162 Connection

1) Install a cable, Belden 8302 or equivalent, from the Felcom 15 Junction Box

to the FS-1570/FS-2570 transceiver. Connect this cable per the notations on

Pg. S-6, the Felcom 15, IC-315 Junction Box Connections.

(Refer to Pg. 2-2, the RC1815 and RC1825 Mechanical Layout for the location of

the IC-315 Junction Box)
