4. RC1815/RC1825 Equipment Installations
4-7
4.5 IB-583 NBDP Terminal
Refer to Installation Manual, FS-1570 (150W) / FS-2570 (250W)
4.5.1 Mounting
1) Mount the IB-583 in the front, desktop area, of the console on the left side.
Using the four tapping screws provided.
(Refer to Pg. 2-2, the RC1815 and RC1825 Mechanical Layout and
Pg. 4-4 of the Installation Manual)
4.5.2 Power Connections
1) Connect power cable, IB-583 Power, to the IB-583 display.
4.5.3 Additional Connections
1) Connect the printer cable, IB-583 Printer, to the printer port.
2) Connect control cable, IB-583 DTE, to the DTE port.
3) Connect the keyboard to the Keyboard port on the IB-583.
To Next Page
