Fusion EN-AM8001 Service Manual

3/4
2…
RESMO102P681JR Resistor 2 R43~44
2…
ST3DOWHI002R Terminals 1 CON1
2…
ST4DOWHI002R Terminals 1 CON2
2…
SW12P3T06002R Power switch 1 SW1
2…
TRA2SA1694R Transistor 2 Q113~114
2…
TRA2SC4467R Transistor 2 R111~112
2…
TRA2SC945R Transistor 1 Q101
2…
TRAA06R Triode 1 Q107
2…
TRAKTB631KR Transistor 1 Q110
2…
TRAKTD600KR Transistor 1 Q109
2…
TRR29618001R Transformer 1 TR1
2…
VRRB50301J1501R VR 2 VR2.VR4
2…
W020831002R copper pad 1 01~02
2…
W051P2207001R ground wire 1 GND
1…
E-ENAM6001
2…
FUS0430R032VR fuse 1
1…
A-ENAM6001
2…
BRA0300102R BAR 3
2…
BRA0420102R BAR 2
2…
BRAPP400201R Bracket 4
2…
BZB20100T5R BZ 1 For slide switch
2…
ECEN300201R plastic endcap 1
2…
ECEN300202R plastic endcap 1
2…
EVA08125TR EVA foam 1 Q107
2…
FPEN6001R front panel 1
2…
HSEN6001R heatsink 1
2…
INN08030T7R insulation pad 4 For copper pole
2…
RPEN6001R rear panel 1
2…
SC5R0901R copper pole 4 To fix PCB
2…
SD3R3LZR pad 1 For ground wire
2…
SD8R0GZR pad 1 For varistors
2…
SF3R0DHR screw nut 4 For panels
2…
SIP035240101R pad 2
2…
SIP048290101R pad 2
2…
SM3R006PKR screw 8 For copper pole and side panel
2…
SM3R008SKR screw 4 For end caps
2…
SM3R014SKR screw 1 For plastic ones
2…
SM4R013GKR screw 5 For bars
2…
SP2R006PKR screw 2 For fuse holder
2…
SP3R005PKR screw 2 For varistors and ground wire
SP3R006PKR screw 4 For bracket
SP3R008PKR screw 11
For front panel、RCA、terminal
1…
B-ENAM6001
2…
BCEN6001R Bottom chassis 1
2…
BGF350360R PE bag 1
2…
BOXEN6001R master carton 0.25
2…
EVA081750T5R EVA pad 2 For bottom chassis
2…
GIBEN6001R Giftbox 1
2…
INSEN6001R manual 1

Fusion EN-AM8001 Specifications

General

Brand	Fusion
Model	EN-AM8001
Category	Amplifier
Language	English
