Fusion FM-402 Brochure & Specs

MARINE SPEAKERS
500 SERIES MARINE STEREO
CD STEREO
MS-CD500
The 500 Series CD Stereo includes the same great benefits
as the MS-IP500, but features a CD/MP3 drive instead of an
internal iPod dock. CD / CD-R / CD-RW, MP3 playback. For true
flexibility add the External Dock for iPod (MS-IPDOCK) and
gain all the benefits of FUSION’s unique iPod connectivity.
500 SERIES COMMON FEATURES
3.2” Greyscale LCD display
Powerful D-Class 70W x 4 (Max)
Multi-Zone control for different levels of volume in
different areas of the boat from a single source of audio
High Quality AM/FM Tuner, RDS
Auxiliary in
Direct access source control
Electronic Skip Protection (MS-CD500 only)
»
»
»
»
»
»
»
Fully integrated iPod user interface
360˚ IPx5 Waterproof rating, which includes full behind
dash water protection
4 Zone configurable (Zone 3 and 4 require an amplifier)
Sirius satellite capable (USA only)
Large rotary encoder and rubber back lit buttons for
simple operation on a moving boat
Electronic bass / treble / balance control
»
»
»
»
»
»
STEREO FOR iPod
MS-IP500
The first Marine Stereo in the world to feature True Internal
iPod docking. Your iPod actually sits inside a waterproof
dock within the Stereo, completely protected from the harsh
marine elements.
Features True iPod Integration, enabling complete control and
navigation of iPod functions from the Stereo menu.
Fusion Alpha Search Technology (FAST) allows for quick
navigation of your iPod data
Zone line out (4 x stereo, 2 x subwoofer)
Zone subwoofer level control
Variable back light illumination
Rotary encoder volume control
12/24 hour Clock
Available in both metallic grey and white
»
»
»
»
»
»
»
MS-IP500, internal iPod dock system
FULL RANGE SPEAKERS
MS-FR402 - 4” 2-WAY SPEAKERS
MS-FR602 - 6” 2-WAY SPEAKERS
MS-FR702 - 7” 2-WAY SPEAKERS
FUSION’s Marine Speakers are designed and engineered from
the ground up to incorporate state of the art audio innovation
never seen before in marine speakers. Our Full Range Marine
Speakers are engineered to minimise magnetic interference.
6” and 7” speakers come complete with three grille options
at no extra cost.
BOX SPEAKERS
MS-BX402
FUSION’s Marine/Outdoor Box Speakers are carefully designed
and manufactured specifically for marine/outdoor use.
FUSION Box Speakers feature a unique high tech bass/
mid cone, a fluid cooled titanium dome tweeter, and are
constructed to be water resistant and minimise magnetic
interference.
CUBE SPEAKERS
MS-BX225
FUSION’s Internal Cube Speakers offer cabin-filling stereo
performance from a small, versatile package. The dual pivot
design with adjustable gimbal bracket, enables a range of
different installations; free standing, wall or ceiling mounted.
Combining FUSIONS Active Subwoofer creates a complete
sound solution.
FUSION’S TRUE MARINE SPEAKERS INCORPORATE CURV CONE TECHNOLOGY MANUFACTURED FROM A
WOVEN POLYPROPYLENE COMPOSITE WHICH IS THEN HEAT PRESSED TO FORM A LIGHTER, STRONGER
CONE, CREATING GREATER DEFINITION OF SOUND, HIGHER OUTPUT AND RESISTANCE TO THE HARSH
MARINE ENVIRONMENT

Fusion FM-402 Specifications

Power

maximum power output	70W x 4
pre-output voltage	3 V/10 k ohms
operating voltage	+10.2 - 16 VDC

Audio Specifications

frequency response	90 – 22kHz
efficiency	87db
impedance	4 ohms

Weight and Dimensions

magnet structure	60 Oz
enclosure dimensions	515 x 233 x 190mm
min. mounting depth	115mm
