Page #10 background imageLoading...
Page #10 background image
10
4 Ohm
4 Ohm
2.67 Ohms
8 Ohms
8 Ohm
4 Ohm
PARALLEL WIRING FORMULA FOR 2 SPEAKERS
R1 x R2
= LOAD IMPEDANCE
R1 + R2 = LOAD IMPEDANCE
= 2.67 Ohms=
4 Ohms x 8 Ohms 32
R1 + R2 4 Ohms + 8 Ohms 12
SERIES WIRING FORMULA FOR 2 SPEAKERS
