LISTENING TO AUXILIARY INPUT
The RA50 can accept audio from devices with an audio output such as an MP3 player, TV,
games console, computer or DVD player.
Note: An adaptor cable may be required.
The Left and Right AUX input RCA cable is located at the rear of the unit.
To listen to input from an auxiliary device:
Press the Input source key ( ) until the AUX input source screen is displayed.
Continuing to press the key will display the input source screens for AM, FM and iPod
(if connected) as described in the section “Input Source Screens” on page 13.
AUXILIARY SOURCE SCREEN
The input source screen displayed when you select auxiliary input is shown in Figure 4 below.
Figure 4 – Example of auxiliary input source screen
AUXILIARY INPUT
17
MOUNTING THE UNIT
Important! If any modification to the vessel is required, such as drilling holes, FUSION
recommends that you consult with your boat dealer or manufacturer beforehand.
1. Create mounting hole for product and drill screw pilot holes. Refer to mounting template
included with product or download from www.fusionelectronics.com
2. Fit mounting gasket.
3. Insert the unit into the mounting hole.
4. Use the supplied 4 x self tapping screws, to fix the unit into position.
5. Attach screw covers.
Note: Appropriate mounting is very important to ensure correct operation. Select a
location that allows both free/open airflow around rear of chassis, whilst minimizing
exposure to moisture. Allow adequate room at the rear of the unit for the cable looms
(approx. 50 mm or 2”).
INSTALLING THE RA50
Figure 5 – Locating the RA50 unit into the mounting panel
