MS-UD750
ISO WIRING LOOM
4 X L+R LINE OUTS
AND 4 X SUB OUTS
SUB RIGHT LEFT
2 X AUX IN
NMEA 2000 CONNECTOR
(NO ADDITIONAL CABLES
REQUIRED) SWITCH
BETWEEN POWERED AND
UNPOWERED NETWORK
ETHERNET
CONNECTOR
REAR USB
CERTIFIED SIRIUS
XM CONNECTOR
ANTENNA
CONNECTOR
CONNECTORS
PROTECTED WITH
RUBBER CAP WHEN
NOT IN USE
