6
DISASSEMBLY
STEP 1
Remove pusher from the chute.
STEP 2
Lower the locking bar (silver)
into the disengaged position
as shown.
STEP 3
Remove lid with built-in
pulp guard by pulling off
of receptacle.
IMPORTANT: Before disassembling the unit make sure you turn the power
OFF and unplug the AC cord from the electrical outlet.
1
2
Locking Bar
3
Pulp
Collector
Chute
Pusher
Receptacle
Lid with Built-
In Pulp Guard
To Next Page
