FUTABA 10CAG User Manual

9
CONTENTS AND TECHNICAL SPECIFICATIONS
6SHFL¿FDWLRQVDQGUDWLQJVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH
Your 10CAG, 10CHG or 10CG system includes the following components:
•
T10CAG, T10CHG or T10CG Transmitter
• R6008HS or R6014HS Receiver
• N 55%&+*RQO\RU15-&$*RQO\1L&GEDWWHU\
& Charger
• Switch harness
• Aileron extension cord
• Neck strap
* The set contents depend on the type of set.
Transmitter T10CAG/HG/G
(2-stick, 10-channel, FASST-2.4G system)
Transmitting frequency: 2.4GHz band
Modulation: 2.4G-7ch or 2.4G-10ch, switchable
Power supply: 9.6V NT8S700B Ni-Cd battery
Receiver R6008HS/R6014HS
(Dual antenna diversity)
Power requirement: 4.8V or 6.0V battery or regulated
output from ESC, etc.
(*1)
6L]H5+6[ [LQ[[PP
R6014HS: 2.06 x 1.48 x 0.63 in. (52.3 x 37.5 x 16.0 mm)
:HLJKW5+6R]J5+6R]J
(*1)
Be sure that when using ESC's regulated output the
capacity of the ESC must meet your usage condition.
Usage condition on "High Speed mode"
(R6008HS/R6014HS)
CAUTION
When using the R6008HS/R6014HS in the high
speed (HS) mode, digital servos are required for
WKH¿UVWVL[FKDQQHOV
,IDQDQDORJVHUYRLVFRQQHFWHGWRRQHRIWKH¿UVWVL[
channels when in the high speed mode, the servo
will not function properly. Additionally, while many
peripheral devices will operate in either the high
speed or normal mode, some will not. If there are
any difficulties noted, please return the reciver's
operational mode to the "Normal" mode to determine
LIWKLVUHVROYHVWKHGLI¿FXOW\
If using the R6008HS in the high speed mode, analog
servos may be used for channels seven and eight. If
using the R6014HS in the high speed mode, analog
servos may be used for channels seven to 12 and for
DG1 and DG2.
(For Operation Mode Selection, see p.20)
(Suggested Servo for use with your 10CG system)
Servo S9252 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 91.7 oz.-in. (6.6 kg-cm) at 4.8V
2SHUDWLQJVSHHGVHFDW9
Size: 1.57 x 0.79 x 1.44 in. (40 x 20 x 36.6 mm)
Weight: 1.76 oz. (50 g)
Servo S9255 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 125.0 oz.-in. (9.0 kg-cm) at 4.8V
2SHUDWLQJVSHHGVHFDW9
Size: 1.57 x 0.79 x 1.44 in. (40 x 20 x 36.6 mm)
Weight: 1.94 oz. (55 g)
Servo S3151 (Standard, Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 43.1 oz.-in. (3.1 kg-cm) at 4.8V
2SHUDWLQJVSHHGVHFDW9
Size: 1.59 x 0.79 x 1.42 in. (40.5 x 20 x 36.1 mm)
Weight: 1.48 oz. (42 g)
Servo S3001 (Standard, ball-bearing)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 - 6.0V (from receiver)
Output torque: 41.7 oz.-in. (3.0 kg-cm)
2SHUDWLQJVSHHGVHF
Size: 1.59 x 0.78 x 1.41 in. (40.4 x 19.8 x 36 mm)
Weight: 1.59 oz. (45.1g)
