Magnus Hedlund Page 12
ADDITIONAL INFORMATION
Reduced rate for Elevator: (when Motor = Turbo)
GLIDER - DUAL RATE
Set flight condition = ‘MOTOR ON’
D/R 2 ON Elevator SF (ON in-flight condition ‘MOTOR ON’)
GLIDER – AFR
(Elevator – Dual rate)
D/R 2 in flight condition ‘MOTOR ON’:
Set Rate A = Rate B = “reduced rate”
Thermal ++
GLIDER – Trim mix 2
When Flight Condition = ‘THERMAL’, add extra aileron/flap camber.
Select for example SF (spring-loading returning switch) to
activate the mix.
Adjust flap “along the way” in Butterfly-mix: (‘LANDING’)
GLIDER – PROGRAM MIXES
Mode = Mixing, Group = separate
Mixing menu 2:
ON (In flight condition ‘LANDING’, other = INH)
Master = J3
Slave = Flap (2) (Select the flap to be adjusted)
Mixing menu 1:
Offset = nnn (Set the value)
Rate A = - Rate B: (Set the position when Brake = max)
