41
REFERENCE
3D 3D mode. p19
A
ACGA/B Rudder control gain
(AVCS) p17
AFR AFR function.
ATV ATV function. Steering angle
adjustment function.
AVC AVCS mode.
AVCS AVCS system. AVCS mode.
AVS AVCS sense. p20
C
CMT Normal/AVC switching mode.
D
D1DA Control delay. p17
D1IA Control delay. p17
D/R Dual rate function.
DUO T9Z dual gain control mode.
F
F3C F3C mode. p19
Fmod Flight mode. p19
G
G:1A/N Gyro gain 1 side. p16
G:2A/N Gyro gain 2 side. p16
GDir Gyro reverse. p16
GYRO T9Z gyro sense mixing.
H
Hello Power on screen display.
High High side.
I
IDLE Transmitter power OFF state.
INH Use inhibited state.
L
LCD Liquid crystal display screen.
LmtA/B Linkage limit setting. p20
Low Low side.
LOW BAT Low battery error
display.
M
Mode Operation mode setting. p18
N
NCGA/B Rudder control gain
(Normal) p17
NOR Normal mode. Normal side.
P
PMIX Programmable mixing.
R
REV Reverse side.
T
Trk Gain tracking. p18
Definition of Abbreviations
The following defines the abbreviations and symbols used in this
manual in alphabetical order. The function names are given on the
description pages.
