FUTABA Sky Leaf Samba f User Manual

7
Wrench
Woodwasher
×10
WingBolt
Tireshaft
M4Nut
M3Washer
M3×10Hexagon
headbolt
×2
×2
M3×16
Tappingscrew
×4
M3×10
Tappingscrew
×4
M2×8Tapping
screw
×6
×2
M3Nut
×2
M2×12Hexagonheadbolt
×4
M2×10Hexagonheadbolt
×4
M2Nut
×8
M2Washer
×8
RaisedBallLink
×4
×4
BallLink
×8
M2×5TappingScrew
ServoArm
ControlHorn
M2×20 Screw
M2Nut
Tailgearrod
Tailgearmount
Tailgeararm
Tailguide
Tailtire
×2
×1
×1
×1
×1
×1
×1
M2.3×12
Tappingscrew
ElevatorRod
AileronRod
AileronRod
RudderRod
ServoS3776SB
Fortheservoincluded
version
*Screwnutwashermaybeincludedextra.
*ALLpartsaresubjecttochangewithoutpriornotice.
MainGear
MainTire
Zip-tie
Hook-and-LoopTape
Hook-and-LoopTape
Hook-and-LoopBand
WheelPants

FUTABA Sky Leaf Samba f Specifications

General

Brand	FUTABA
Model	Sky Leaf Samba f
Category	Toy
Language	English
