FUTABA Sky Leaf Samba f User Manual

8
źƌƑƊŃŤƖƖƈƐƅƏƜ
3
Ŕ
Ŗ
ř
ŕ
ŗ
Ř
Aileron
Wing
● Holdverticallytomakesurethattheglue
wicksthepaperhingetobothsurfaces.
● Pushtheaileronintothewings.
Gluethepaperhingetotheaileron.
NoClearance
● Gluethecontrolhornsintotheailerons.
CAglue
ControlHorn
Aileron
Gapisneeded.
● Fitthepaperhingesintothewing,making
surethatyoualigneachone.
Pushin
Pushin
● Movetheaileronsafterdrying.
● Holdverticalinthedirectionthat
youwanttogluetowickintothe
paperhingeandsurface.
！ Makegluewicktotheinterior.
● Ruffupthebottomofthecontrol
hornwithsandpapertohelpthe
gluesticktothehorn.
！ Makegluewicktothe
interior.
● Paperhinge
● Hardpoint
